Zinc Alloy Exit Button Switch – Door Access Control NO/NC/COM
Zinc Alloy Exit Button Switch – Door Access Control NO/NC/COM
Asia-Teco Zinc Alloy Exit Button – Door Access Control Push-to-Exit Switch
Upgrade your access control system with the Asia-Teco Zinc Alloy Exit Button Switch. Built from durable die-cast zinc alloy, this push-to-exit release button is engineered for commercial and residential door access control installations. Its compact form factor, rugged construction, and reliable NO/NC/COM signal output make it an excellent choice for electric locks, magnetic locks, and access panels.
Key Features
- Heavy-Duty Zinc Alloy Body – Corrosion-resistant construction stands up to high-traffic environments
- Versatile Signal Output – Supports NC/NO/COM configurations for flexible integration with any access control panel
- Wide Electrical Compatibility – Rated at 3A @ 36VDC; operates on DC12V supply voltage
- Multiple Model Options – Available in models Z35, Z30, Z53LS, Z30LS, Z30M2G, Z53M2G, and Z53K to suit various installation requirements
- Compact & Lightweight – Measures 80 × 30 × 25 mm and weighs just 85g for easy flush or surface mounting
- Simple Wiring – Clear terminal labeling ensures fast, mistake-free installation
- 1-Year Warranty – Backed by a full one-year manufacturer warranty from the date of purchase
Specifications
| Brand | Asia-Teco |
| Models | Z35 / Z30 / Z53LS / Z30LS / Z30M2G / Z53M2G / Z53K |
| Material | Zinc Alloy |
| Supply Voltage | DC 12V |
| Electrical Performance | 3A @ 36VDC |
| Signal Output | NC / NO / COM |
| Dimensions | 80 × 30 × 25 mm |
| Weight | 0.085 kg (85g) |
| Country of Origin | Made in China |
Ideal Applications
- Office and commercial building access control systems
- Apartment complex entry doors
- Warehouses, server rooms, and secure storage areas
- Electric strike locks and magnetic lock installations
- Retrofit or replacement of existing exit buttons
Warranty & Support
This product is backed by a 1-year warranty from the date of purchase. If you experience any issues, please contact us before leaving feedback so we can resolve any concerns promptly.
For general guidance on door hardware safety and building access standards, visit the U.S. Consumer Product Safety Commission (CPSC).
Frequently Asked Questions
Q: What signal output modes does this exit button support?
A: The Asia-Teco zinc alloy exit button supports Normally Closed (NC), Normally Open (NO), and Common (COM) signal outputs, giving you full flexibility to integrate it with virtually any door access control panel or electric lock system.
Q: What voltage does this push-to-exit switch require?
A: This exit button operates on a DC 12V supply voltage and is rated for 3A at 36VDC electrical performance, making it compatible with most standard access control power supplies.
Q: Is this exit button suitable for outdoor or high-traffic door installations?
A: Yes. The die-cast zinc alloy housing is designed for durability and resistance to wear, making it well-suited for high-traffic commercial doors, office entryways, and secure access points. For outdoor use, ensure the installation location provides adequate weather protection.
Q: Which model number should I choose for my installation?
A: Several model variants are available — Z35, Z30, Z53LS, Z30LS, Z30M2G, Z53M2G, and Z53K. Model differences typically relate to button size and mounting configuration. Please refer to your access control system's specifications or contact us to confirm which model best fits your setup.
