Smart WiFi RFID Access Control Reader – IP67 Waterproof, 10,000 Users
Take control of who enters your property with the Asia-Teco H18/HF18 Smart WiFi RFID Access Control Reader. Designed for both residential and commercial use, this robust reader combines 2.4G Wi-Fi connectivity, Wiegand (WG) input/output, and dual-frequency RFID card support into one sleek, tamper-resistant unit. Manage up to 10,000 users remotely from the Smart Life mobile app — no on-site programming required.
⚠ Important Note: This reader is available in either 125 KHz or 13.56 MHz frequency — it is not a dual-band device. Fingerprint functionality (100-fingerprint capacity) is only available on the HF18 (fingerprint) version. Please select the correct variant for your card type and needs before ordering.
Key Features
- IP67 Waterproof & Anti-Vandal Housing – Built to withstand harsh outdoor environments and unauthorized tampering
- 2.4G Wi-Fi Connectivity – Integrates with the Smart Life platform for real-time remote management and temporary access control
- Dual-Frequency Options – Available in 125 KHz (EM card) or 13.56 MHz (MIFARE card) — select one at time of purchase
- 10,000 User Capacity – Ideal for large apartment complexes, offices, and commercial facilities
- Wiegand Input/Output (WG) – Seamlessly integrates with existing access control systems
- Multiple Entry Methods – RFID card swipe, mobile app unlock, and fingerprint recognition (HF18 only, up to 100 fingerprints)
- Wide Operating Range – Functions from -40°C to 60°C and 10%–99% humidity for year-round reliability
- Temporary Access Grants – Issue time-limited credentials for guests, contractors, and delivery personnel
- Fail-Secure Mode – Door defaults to locked in the event of a power interruption
- CE & FCC Certified – Meets international safety and radio frequency standards
Technical Specifications
| Model | H18 / HF18 |
| Brand | Asia-Teco |
| Card Frequency | 125 KHz (EM) or 13.56 MHz (MIFARE) — single band per unit |
| Reading Range | Up to 60 mm |
| User Capacity | 10,000 |
| Fingerprint Capacity | 100 (HF18 only) |
| Entry Methods | RFID card, mobile app, fingerprint (HF18) |
| Connectivity | 2.4G Wi-Fi (Smart Life platform) |
| Interface | Wiegand Input/Output |
| Security Mode | Fail Secure |
| Working Voltage | DC 10–24V |
| Standby Current | 50 mA |
| Working Current | 120 mA |
| Working Temperature | -40°C to 60°C |
| Working Humidity | 10%–99% |
| IP Rating | IP67 (Waterproof) |
| Certification | CE, FCC |
| Country of Origin | Made in Mainland China |
What's in the Box?
- 1 × Asia-Teco H18 or HF18 RFID Access Control Reader
- Installation hardware and documentation
Who Is This For?
Whether you're securing a commercial office building, an apartment block, a parking facility, or a gated community, the Asia-Teco H18/HF18 gives you enterprise-grade access management without the complexity. Its seamless Smart Life app integration means you can add, remove, or grant temporary access to users from anywhere in the world.
For more information on best practices for physical access control security, visit the Cybersecurity & Infrastructure Security Agency or refer to the NIST guidelines on security technologies.
Frequently Asked Questions
Q: Is this RFID access control reader dual-band (125 KHz + 13.56 MHz)?
A: No. The Asia-Teco H18/HF18 is available in either 125 KHz (EM card) or 13.56 MHz (MIFARE card) — not both simultaneously. Please confirm which card frequency your existing system uses before selecting your variant.
Q: Does the fingerprint function work on all versions?
A: No. Fingerprint recognition (up to 100 fingerprints) is exclusively available on the HF18 fingerprint version. The standard H18 model supports RFID card and mobile app entry only.
Q: Can I grant temporary access to guests or contractors?
A: Yes. Via the Smart Life mobile app, you can issue temporary, time-limited access credentials remotely — ideal for delivery personnel, cleaning staff, or short-term visitors — without needing to be on-site.
Q: Is this reader suitable for outdoor installation?
A: Absolutely. With an IP67 waterproof rating, anti-vandal construction, and an operating temperature range of -40°C to 60°C, this reader is purpose-built for demanding outdoor environments.
Q: Does it work with existing Wiegand-based access control systems?
A: Yes. The H18/HF18 features standard Wiegand (WG) input/output, making it compatible with most existing access control panels and third-party systems that support the Wiegand protocol.
