Asia-Teco WiFi Fingerprint Access Control Reader – Smart Door Lock with RFID & Tuya App
Upgrade your home or business security with the Asia-Teco TF108 WiFi Fingerprint Access Control Reader — a next-generation smart entry system that combines biometric fingerprint scanning, RFID card access, PIN entry, and full Tuya App remote control in one sleek, weatherproof unit. Whether you're managing a residential gate, office door, or commercial entrance, this all-in-one smart lock reader delivers fast, reliable, and keyless access for everyone on your list.
Made in Mainland China.
Why Choose This Smart Access Control Reader?
- Multiple Access Methods: Open doors via fingerprint, RFID card, PIN code, Tuya App, app-generated temporary passwords, or multi-user combination — maximum flexibility for every scenario.
- Tuya Smart App Integration: Manage users, grant visitor access, generate temporary codes, and monitor door events remotely from your smartphone.
- Dual-Frequency RFID Support: Compatible with both 125 kHz (EM) and 13.56 MHz (Mifare) cards — works with a wide range of existing card systems.
- IP66 Waterproof Rating: Built for outdoor use, withstanding rain, dust, and harsh weather conditions with confidence.
- Anti-Vandal ABS + PC Shell: Rugged construction resists tampering, prying, and impact — ideal for high-traffic or exposed entry points.
- High User Capacity: Store up to 100 fingerprints + 2,800 cards locally, or manage 100 fingerprints + 400 cards via app, plus 10 visitor user slots.
- Wiegand Interface: Functions as a professional Wiegand card reader with Mifare Wiegand 26–58 bit and EM Wiegand 26-bit support — seamlessly integrates with existing access control panels.
- Door Contact Detection: Built-in door status monitoring alerts you if the door is left open.
- Pulse & Toggle Output Modes: Flexible relay output options to suit a wide range of gate controllers and electric locks.
Key Specifications
| Brand | Asia-Teco |
| Model | TF108EM/MF-WiFi |
| Smart Platform | Tuya |
| RFID Frequency | 125 kHz (EM) + 13.56 MHz (Mifare) |
| Fingerprint Capacity (Local) | 100 |
| Card Capacity (Local) | 2,800 |
| App Fingerprint Capacity | 100 |
| App Card Capacity | 400 |
| Visitor Users | 10 |
| Waterproof Rating | IP66 |
| Shell Material | ABS + PC |
| Wiegand Output | Mifare: 26–44 bit, 56 bit, 58 bit; EM: 26 bit |
| PIN Wiegand Output | 4-bit, 8-bit (ASCII), 10-digit virtual card number |
| Connectivity | WiFi |
| Country of Origin | Mainland China |
Access Modes at a Glance
- 🔏 Fingerprint — fast biometric entry
- 💳 RFID Card — tap & go with EM or Mifare cards
- 🔢 PIN Code — secure numeric entry
- 📱 Tuya App — remote unlock from anywhere
- 🔑 Temporary Password — app-generated codes for guests
- 👥 Multi-User Combination — require two or more credentials for high-security doors
Learn More About Smart Home Security
For guidance on best practices for home security devices and consumer product safety, visit the U.S. Consumer Product Safety Commission (CPSC).
Frequently Asked Questions
Q: Does this WiFi fingerprint access control reader work with the Tuya Smart app?
A: Yes! The Asia-Teco TF108 WiFi fingerprint access control reader is fully integrated with the Tuya Smart platform. Simply download the Tuya or Smart Life app, connect the device to your home WiFi network, and manage users, unlock doors remotely, generate temporary access codes for visitors, and monitor door status — all from your smartphone.
Q: What RFID card types are compatible with this smart door lock reader?
A: This access control reader supports both 125 kHz EM cards and 13.56 MHz Mifare cards, making it compatible with a wide range of standard access control cards and key fobs already in use at most homes, offices, and commercial properties.
Q: Is this access control reader suitable for outdoor installation?
A: Absolutely. The unit carries an IP66 waterproof rating, meaning it is fully protected against powerful water jets and heavy rain, as well as dust ingress. Its anti-vandal ABS + PC shell provides additional protection against tampering and physical impact, making it ideal for outdoor gates, building entrances, and perimeter doors.
Q: Can I connect this reader to an existing Wiegand access control panel?
A: Yes. The TF108 supports professional Wiegand output — Mifare Wiegand 26–44, 56, and 58 bits, and EM Wiegand 26-bit — so it can be used as a standalone smart lock controller or as a card reader connected to a third-party Wiegand-compatible access control panel. PIN Wiegand output is also supported in 4-bit, 8-bit (ASCII), and 10-digit virtual card number formats.
Q: How many users can be stored on this fingerprint access control device?
A: The device supports up to 100 fingerprints and 2,800 RFID cards stored locally, plus 100 fingerprints and 400 cards managed through the Tuya App. An additional 10 visitor user slots are available for temporary or guest access — perfect for Airbnb hosts, small businesses, and property managers.
