Tuya WiFi/Zigbee 3-Phase Smart Energy Meter | Modbus RTU
Tuya WiFi/Zigbee 3-Phase Smart Energy Meter | Modbus RTU
Tuya WiFi/Zigbee 3-Phase Bidirectional Smart Energy Meter
Take full command of your home or commercial electrical system with this advanced 3-Phase Bidirectional Smart Energy Meter. Compatible with the Tuya Smart and Smart Life apps, this device delivers real-time monitoring of voltage, current, and power consumption across all three phases — right from your smartphone. Whether you're managing energy costs, optimizing consumption, or integrating with a smart home system, this meter delivers professional-grade visibility and control.
Made in Mainland China.
Key Features
- Real-Time Monitoring: Track voltage, current, and power usage per phase instantly via the Tuya Smart or Smart Life app.
- Bidirectional Metering: Measures both import and export energy — ideal for solar panel setups and grid-tied systems.
- Multi-Tariff Support: Manage and query power consumption statistics at any time with multi-tariff energy tracking.
- Remote Relay Control: Switch the relay on or off remotely through the app from anywhere in the world.
- Modbus RTU Support: Seamlessly integrates with industrial and building automation systems via Modbus RTU protocol.
- Pulse Optical Coupler Interface: Supports a pulse output socket with configurable output parameters.
- Home Automation Ready: Create scenes, automations, and schedules directly in the Tuya ecosystem.
- Wide Temperature Range: Operates reliably from -25°C to 55°C for indoor and semi-outdoor installations.
Specifications
| Connectivity | WiFi 2.4GHz / Zigbee 3.0 2.4GHz |
| Compatible App | Tuya Smart / Smart Life |
| Current Range | 0.25A – 80A |
| Power Input | AC 3×110/190V or 230/400V |
| Protocol | Modbus RTU |
| Operating Temperature | -25°C to 55°C |
| Dimensions | 126 × 98 × 30 mm |
| Battery | Not required |
| Origin | Mainland China |
What's in the Box
- 1× 3-Phase Smart Energy Meter
Important Notes
- Color may vary slightly from product images due to screen calibration and lighting differences.
- Please allow a 1mm–1cm dimensional variance due to manual measurement.
- Installation should be performed by a qualified electrician in compliance with local electrical codes.
For guidance on electrical safety standards and smart metering, visit the U.S. Department of Energy – Home Energy Audits resource.
Frequently Asked Questions
Q: Does this 3-phase smart energy meter work with both WiFi and Zigbee?
A: Yes — this Tuya energy meter is available in both a WiFi (2.4GHz) version and a Zigbee 3.0 (2.4GHz) version. Choose the connectivity type that best suits your smart home or building automation setup. Both versions are fully compatible with the Tuya Smart and Smart Life apps.
Q: Can this meter be used with solar panels or bidirectional energy systems?
A: Absolutely. The bidirectional metering capability allows the device to measure both imported and exported power, making it well-suited for grid-tied solar installations where you want to track energy flowing both from and back to the grid.
Q: What is Modbus RTU and why is it useful?
A: Modbus RTU is a widely used serial communication protocol in industrial and building automation systems. Support for Modbus RTU means this energy meter can be integrated with PLCs, SCADA systems, and other automation infrastructure — greatly expanding its usability beyond standard consumer smart home setups.
Q: What current range does this energy meter support?
A: The meter supports a current range of 0.25A to 80A, making it versatile for residential, light commercial, and small industrial three-phase electrical systems operating at AC 3×110/190V or 230/400V.
