Three-Wire Motor Speed Controller for 12V/24V Diaphragm Pumps
Three-Wire Motor Speed Controller for 12V/24V Diaphragm Pumps
Three-Wire Knob Motor Speed Controller — Built for Diaphragm & Vacuum Pumps
Take precise control of your 12V or 24V three-wire diaphragm pump with this dedicated Motor Speed Regulator Drive Board. Featuring an intuitive knob-style speed control interface and reliable terminal connections, this compact controller lets you dial in exactly the output speed you need — whether you're managing a vacuum pump, fluid transfer system, or custom electronics project.
Key Features
- Knob Speed Control: Simple, responsive rotary knob allows smooth, stepless adjustment of motor output speed.
- Wide Voltage Compatibility: Supports both 12V and 24V three-wire diaphragm pumps for flexible application across multiple setups.
- Terminal Connection Interface: Secure, easy-to-wire terminal block connection for a stable and reliable electrical connection.
- Wide Operating Temperature: Rated for ambient temperatures of -25°C to 65°C (non-icing conditions), making it suitable for diverse environments.
- Humidity Resistant Design: Operates reliably in ambient humidity of 35–95% (non-condensing).
- Compact Drive Board Format: Space-saving PCB form factor fits neatly into enclosures, project boxes, or mounting panels.
- Dedicated Design: Engineered specifically for three-wire diaphragm and vacuum pump applications requiring knob-based speed regulation.
Specifications
- Speed Control Mode: Knob speed control
- Pump Interface: Terminal connection
- Supported Voltage: 12V / 24V DC
- Compatible Motor Type: Three-wire DC diaphragm pump / vacuum pump
- Ambient Temperature: -25°C to 65°C (non-icing)
- Ambient Humidity: 35–95% (non-condensing)
- Country of Origin: Made in Mainland China
What's in the Box
- 1× Three-Wire Motor Speed Regulator Drive Board
Important Notes
- Due to variations in lighting and screen calibration, actual product color may differ slightly from images shown.
- Please allow a tolerance of 1mm–1cm due to manual measurement.
For additional guidance on electrical safety and best practices when working with motor control circuits, visit the OSHA Electrical Safety Resource.
Frequently Asked Questions
Q: What types of pumps is this motor speed controller compatible with?
A: This speed regulator drive board is specifically designed for three-wire 12V and 24V DC diaphragm pumps and vacuum pumps. It is ideal for applications requiring knob-based, stepless speed control via a terminal connection interface.
Q: How do I connect the motor speed controller to my pump?
A: The drive board uses a terminal block connection interface. Simply wire your three-wire diaphragm or vacuum pump leads into the corresponding terminals on the board, connect your 12V or 24V DC power supply, and use the rotary knob to adjust motor output speed as needed.
Q: Can this speed controller be used outdoors or in humid environments?
A: Yes. The controller is rated for ambient temperatures between -25°C and 65°C (non-icing) and operates in humidity levels of 35–95% (non-condensing), making it suitable for a range of indoor and sheltered outdoor applications.
