Monitor and manage your three-phase electrical consumption with precision using this wall-mounted LCD Digital Energy Meter. Designed for industrial, commercial, and heavy-duty residential applications, this kWh meter delivers accurate, real-time electricity measurement across three-phase 4-wire systems operating at AC 400V and up to 100A. Its clear LCD display and compact DIN rail-compatible design make installation and daily monitoring straightforward and efficient.
Key Features
- Wide Current Range: Rated at 5A with a maximum capacity of 100A — suitable for a broad range of three-phase loads.
- AC 400V / 50Hz Compatible: Engineered for standard three-phase 4-wire power systems at 400V, 50Hz.
- Clear LCD Display: Large, easy-to-read digital screen shows real-time kWh energy consumption at a glance.
- Pulse Output: 400 imp/kWh pulse frequency with optical coupling isolation ensures accurate metering and safe signal transmission for automation or remote monitoring setups.
- Pulse LED Indicator: Built-in LED flashes with each pulse, providing a quick visual confirmation that the meter is operating correctly.
- DIN Rail Mounting: Standard 35mm DIN rail installation makes panel integration simple and secure.
- Wall-Mounted Design: Compact and sturdy form factor ideal for distribution boards, electrical panels, and control cabinets.
- No Battery Required: Powered directly through the monitored circuit — no external battery needed.
Specifications
| Parameter | Value |
|---|---|
| Rated Voltage | AC 400V |
| Frequency | 50Hz |
| Rated Current | 5A |
| Maximum Current | 100A |
| Pulse Frequency | 400 imp/kWh |
| Pulse Output | Optical coupling isolation |
| Wiring Configuration | 3-Phase, 4-Wire |
| Display | LCD Digital |
| Mounting | 35mm DIN Rail / Wall-Mounted |
| Battery | Not required |
| Country of Origin | Made in China |
What's in the Box?
- 1× Three-Phase 4-Wire LCD Digital Energy Meter
Important Notes
- Actual color may vary slightly from product images due to lighting and screen differences.
- Please allow a 1mm–1cm dimensional tolerance due to manual measurement.
- Installation should be performed by a qualified electrician in accordance with local electrical codes and safety standards.
For guidance on electrical safety and metering standards, visit the OSHA Electrical Safety resource and refer to NIST Electricity Measurement standards for accuracy and compliance information.
Frequently Asked Questions
Q: What type of electrical system is this three-phase energy meter compatible with?
A: This LCD digital energy meter is designed for AC 400V, 50Hz, three-phase 4-wire power systems. It is ideal for industrial panels, commercial buildings, and heavy-duty equipment circuits requiring accurate kWh consumption tracking.
Q: How is this energy meter installed?
A: The meter supports standard 35mm DIN rail installation, making it straightforward to mount inside electrical distribution panels or control cabinets. It can also be wall-mounted. Installation should always be carried out by a licensed electrician following local electrical codes.
Q: What is the pulse output used for on this kWh meter?
A: The 400 imp/kWh pulse output, isolated via optical coupling, allows the meter to interface with external data loggers, building management systems (BMS), or automation controllers. This enables remote energy monitoring and data recording without direct electrical connection to the metering circuit.
Q: Does this energy meter require a battery?
A: No, this meter does not require a battery. It is powered directly through the monitored electrical circuit, eliminating the need for battery maintenance or replacement.
Q: Can this meter handle currents above 5A up to 100A?
A: Yes. While the rated current is 5A, the meter supports a maximum current of 100A, giving you flexibility across a wide range of three-phase load applications.
