Asia-Teco F102 Intelligent Network Access Controller Board
Take full control of your facility's entry points with the Asia-Teco F102 TCP/IP Network Access Controller Board. Designed for turnstiles, channel gates, and door access systems, this intelligent security panel delivers real-time monitoring, flexible credential options, and seamless network integration — all from a single, compact board. Made in Mainland China.
Key Features
- TCP/IP Communication: Connect directly to your existing network for centralized management and remote monitoring across multiple access points.
- Wiegand 26 & 34 Bit Input: Compatible with a wide range of card readers, offering versatile integration with existing hardware.
- Multiple Entry Methods: Supports swipe card and password entry, giving administrators and users flexible access options.
- Large Card Storage: Stores up to 20,000 registered cards onboard, ideal for medium-to-large facilities.
- Offline Support: Continues to operate and grant access even when the network connection is unavailable, ensuring uninterrupted security.
- Real-Time Monitoring: Live access event tracking lets you see who enters and exits at any moment through compatible software.
- Adjustable Door Delay: Door open time is fully configurable from 1 to 600 seconds to suit any operational requirement.
- Fail-Safe Security Mode: Automatically defaults to a safe state in the event of a power failure, protecting occupants and assets.
- Database Compatibility: Works with both Microsoft Access and SQL databases for enterprise-level record keeping and reporting.
- Smart Platform Ready: Compatible with third-party smart management platforms for expanded automation possibilities.
Technical Specifications
| Specification | Details |
|---|---|
| Model | F102 |
| Brand | Asia-Teco |
| Communication Mode | TCP/IP |
| Card Reader Input Format | Wiegand 26 or 34 Bit |
| Entry Methods | Swipe Card, Password |
| Card Storage Capacity | 20,000 Cards |
| Door Delay Time | 1–600 Seconds (Adjustable) |
| Security Mode | Fail Safe |
| Offline Support | Yes |
| Database Support | Microsoft Access / SQL |
| Real-Time Monitoring | Supported |
| Country of Origin | Made in Mainland China |
Who Is This For?
The Asia-Teco F102 is the ideal solution for businesses, schools, residential complexes, warehouses, and any facility requiring dependable, networked access control. Whether you're upgrading an existing turnstile system or building a new access infrastructure, this board delivers professional-grade security with straightforward installation and software integration.
For general guidance on physical security standards and best practices, visit the Cybersecurity and Infrastructure Security Agency (CISA). For information on electrical and hardware safety standards, refer to the U.S. Consumer Product Safety Commission (CPSC).
Frequently Asked Questions
Q: What communication protocol does the Asia-Teco F102 access controller board use?
A: The F102 uses TCP/IP communication, allowing it to connect directly to a standard network switch or router for centralized, remote access management across multiple doors or entry points.
Q: Is the F102 access control board compatible with my existing card readers?
A: Yes. The board accepts Wiegand 26 and Wiegand 34 bit input formats, which are among the most widely used standards in card reader technology, ensuring broad compatibility with most RFID and proximity card readers.
Q: What happens if the network goes down — will access control still work?
A: Absolutely. The F102 supports offline operation, meaning it stores access credentials locally and continues to grant or deny access even without an active network connection. Access events are logged and synced once connectivity is restored.
Q: How many cards can be stored on the F102 controller board?
A: The board can store up to 20,000 registered cards in its onboard memory, making it well suited for medium-to-large deployments such as office buildings, schools, or multi-unit residential facilities.
Q: What databases does the F102 access control system support?
A: The F102 is compatible with both Microsoft Access and SQL databases, offering flexible options for organizations that need robust data management, reporting, and integration with existing enterprise software.
