Asia-Teco Mini TCP/IP Double Door Access Control Panel (Model: WG606)
Take full command of your facility's entry points with the Asia-Teco WG606 Mini TCP/IP Wiegand 26/34 Double Door Access Control Panel. Engineered for businesses, offices, warehouses, and multi-tenant properties, this compact yet powerful network controller manages up to two doors simultaneously — all from a centralized software dashboard with a free API for seamless third-party integration.
Compatible with virtually every major card reader protocol — including Motorola, HID, EM, and Mifare — the WG606 delivers enterprise-grade access management without the enterprise price tag. Made in Mainland China.
Key Features
- TCP/IP Network Connectivity: 10M/100M adaptive Ethernet communication for fast, reliable control across your network.
- Wiegand 26/34 Input: Compatible with a wide range of card readers including Motorola, HID, EM, and Mifare One protocols.
- Large User Capacity: Supports up to 20,000 users and stores 100,000 offline event buffers — records are never lost even during power interruptions thanks to high-speed memory protection.
- Scalable Controller Network: No limit on the number of controllers — expand your system as your facility grows.
- Free Software API: Includes English-language management software supporting both Access and SQL databases, plus a free API for custom integrations.
- Flexible Door Timing: Door open time is fully adjustable from 1 to 600 seconds.
- Long Reader Range: Reader-to-controller distance up to 100m (80m recommended).
- Fail Secure Mode: Doors remain locked in the event of a power failure for maximum security.
- Wide Operating Range: Functions in temperatures from -40°C to 70°C and humidity of 10–90% RH (non-condensing).
Advanced Security Functions
- ✅ Alarm for prolonged door-open, unauthorized entry, and duress situations
- ✅ Remote door open/close capability
- ✅ Anti-passback and anti-tailgating
- ✅ Multi-card door opening (two-person verification)
- ✅ Scheduled long-time door open
- ✅ Electronic map display in software
- ✅ Emergency lockdown
- ✅ First-card unlocking
- ✅ Internal and external validation modes
- ✅ Fire and alarm linkage (hardware alarm available with optional ACB-EA05 expansion board)
Technical Specifications
| Model | WG606-2 Door |
| Communication | TCP/IP 10M/100M Adaptive Ethernet |
| Power Supply | 12VDC, 4–7A |
| Board Power Consumption | <100mA |
| Card Reader Input | Wiegand 26/34 |
| User Capacity | 20,000 Users |
| Offline Event Buffers | 100,000 Records |
| Max Reader Distance | 100m (80m suggested) |
| Door Open Timer | 1–600 Seconds (Adjustable) |
| Operating Temperature | -40°C to 70°C |
| Operating Humidity | 10–90% RH, Non-Condensing |
| Security Mode | Fail Secure |
| Software Database | Access & SQL |
| Country of Origin | Mainland China |
What's in the Box
- PCB Control Board (WG606)
- Management Software (English)
- User Manual
- Certificate of Compliance
- Carton Packaging
Learn More About Physical Access Control
For industry guidance on electronic access control systems and best practices for securing building entry points, visit the Cybersecurity and Infrastructure Security Agency (CISA). You can also reference NIST's cybersecurity resources for physical and logical access control standards.
Frequently Asked Questions
Q: How many doors can the WG606 TCP/IP access control panel manage?
A: The Asia-Teco WG606 is designed as a double door (2-door) access control panel, allowing you to independently manage two entry points from a single controller. You can deploy unlimited controllers on the same network for larger facilities.
Q: What card reader types are compatible with the Wiegand 26/34 input?
A: The panel supports any card reader that uses the Wiegand 26 or Wiegand 34 protocol, including popular brands and technologies such as Motorola, HID, EM, and Mifare One proximity/smart card readers.
Q: Does this access control panel work if the network or power goes down?
A: Yes. The WG606 features high-speed onboard memory that retains up to 100,000 event records even during power interruptions — data is never lost. The panel also operates in Fail Secure mode, keeping doors locked during a power outage to maintain security.
Q: Is programming software included, and can I integrate it with my own system?
A: Yes. The panel ships with English-language management software compatible with both Microsoft Access and SQL databases. A free API is also included, allowing developers to integrate the access control system with third-party platforms, HR software, or custom applications.
Q: What is the maximum distance between the card reader and the controller?
A: The maximum recommended cable run from a card reader to the WG606 controller is 80 meters, with an absolute maximum of 100 meters. Using quality shielded cabling within the recommended range ensures reliable Wiegand signal transmission.
