STM32F407ZET6 24-Channel 12-Bit ADC Data Acquisition Module
STM32F407ZET6 24-Channel 12-Bit ADC Data Acquisition Module
STM32F407ZET6 24-Channel 12-Bit ADC Data Acquisition Module with Type-C Interface
Take your electronics projects to the next level with this powerful STM32F407ZET6-based 24-Channel 12-Bit ADC Sampling Module. Designed for engineers, makers, and hobbyists who need fast, accurate analog-to-digital data acquisition, this module delivers simultaneous multi-channel voltage measurement with a clean Type-C USB interface for modern connectivity.
Key Features
- 24 Simultaneous ADC Channels — Measure up to 24 analog input signals at the same time, making it ideal for complex multi-sensor monitoring applications.
- 12-Bit Resolution — Delivers 4,096 discrete levels of measurement precision across the 0–3V input range for detailed, high-fidelity data capture.
- TVS Protection on Every ADC Port — Each of the 24 input channels is equipped with Transient Voltage Suppression (TVS) protection, safeguarding your module and connected circuitry against voltage spikes.
- Adjustable Measurement Speed via AT Commands — Easily configure the sampling rate through simple AT commands, with a maximum upload speed of up to 10,000 samples per second.
- Real-Time Waveform Visualization — Compatible with the Vofa+ host computer software, enabling live voltage waveform display for intuitive data analysis and debugging.
- Type-C Interface — Modern, reversible USB Type-C connector for reliable, hassle-free connectivity to your PC or development system.
- 0–3V Input Range — Clean and direct voltage input range suitable for a wide variety of sensor outputs and signal sources.
- Powered by STM32F407ZET6 MCU — Built on ST Microelectronics' high-performance ARM Cortex-M4 microcontroller, ensuring fast processing and stable operation.
Specifications
- Microcontroller: STM32F407ZET6 (ARM Cortex-M4)
- ADC Channels: 24 (simultaneous)
- ADC Resolution: 12-Bit
- Input Voltage Range: 0–3V per channel
- Max Sampling Speed: Up to 10,000 samples/second
- Interface: USB Type-C
- Channel Protection: TVS on each ADC port
- Configuration: AT Command set
- Compatible Software: Vofa+ host computer
- Country of Origin: Made in Mainland China
Package Contents
- 1× STM32F407ZET6 24-Channel 12-Bit ADC Sampling Module
Important Notes
- Due to lighting and screen color differences, the actual product color may vary slightly from product images.
- Please allow a 1mm–1cm dimensional tolerance due to manual measurement.
Learn More
For best practices in electronic design and component safety, visit the U.S. Consumer Product Safety Commission (CPSC) and NIST Electronics Resources for technical standards and guidelines.
Frequently Asked Questions
Q: What input voltage range does this ADC sampling module support?
A: This STM32F407ZET6 ADC module supports an input voltage range of 0 to 3V across all 24 channels. Each channel also includes built-in TVS protection to guard against voltage transients.
Q: How do I configure the sampling speed on this 24-channel data acquisition module?
A: The sampling speed is fully configurable via AT commands sent over the USB Type-C interface. The module supports a maximum upload speed of up to 10,000 samples per second, giving you flexibility for both slow precision measurements and fast signal capture.
Q: Is this module compatible with Vofa+ software for real-time waveform display?
A: Yes! This module is designed to work seamlessly with the Vofa+ host computer software, allowing you to visualize voltage waveforms from all 24 ADC channels in real time on your PC.
Q: Can all 24 channels be sampled simultaneously?
A: Yes. One of the core advantages of this module is its ability to perform simultaneous measurement across all 24 ADC channels, making it excellent for multi-sensor data acquisition systems where timing alignment between channels is critical.
