Solar Flame Effect LED Circuit Board – Candle Lamp Controller
Solar Flame Effect LED Circuit Board – Candle Lamp Controller
Solar-Powered Flame Effect Candle Lamp Circuit Board with 12 LED Controllers
Bring a warm, flickering ambiance to your solar candle or garden light projects with this compact 1.2V Solar Flame Light Circuit Board. Designed to simulate a realistic flame-beating lighting effect, this drive board automatically activates at night — no manual switching needed. Whether you're building DIY solar lanterns, replacing worn-out controllers, or stocking up for a craft project, this versatile board delivers consistent, eye-catching results.
Key Features
- Realistic Flame Effect: 12 LEDs produce a dynamic, flame-shaped beating light pattern for a natural candlelight look.
- Auto Night Activation: Built-in light sensor triggers automatic illumination at dusk and switches off at dawn — fully hands-free.
- Solar Compatible: Works with a 2V / <0.4W solar panel and a 1.2V Ni-MH rechargeable battery (button battery type).
- Compact & Lightweight: Measures just 80.8 × 11.8 mm — easy to integrate into candle lamp housings, garden stakes, and decorative fixtures.
- PC + LED Construction: Durable polycarbonate board material ensures long-lasting performance in DIY and outdoor applications.
- Multi-Pack Options: Available in quantities of 1, 5, 10, 15, or 20 boards — ideal for bulk builds and replacements.
- No Batteries Included: Bulbs are included; pair with your own 1.2V Ni-MH battery and compatible solar panel.
Specifications
| Battery Voltage | 1.2V Ni-MH (button battery) |
| Solar Panel Voltage | 2V < 0.4W |
| Lighting Mode | Automatic night activation, flame-beating pattern |
| LED Count | 12 LEDs per board |
| Luminous Flux | 60–249 lm |
| Material | PC + LED |
| Board Dimensions | 80.8 × 11.8 mm |
| Power Source | Solar + Button Battery |
| Batteries Included | No |
| Bulbs Included | Yes |
| Country of Origin | Made in China |
What's in the Box
- 1 × Flame Light Circuit Board (per unit ordered)
Important Notes
- Actual color may vary slightly from images due to monitor and lighting differences.
- Please allow ±1–2 cm measurement deviation due to manual measurement.
- Battery and solar panel are not included — sold separately.
For more information on solar energy and how solar-powered devices work, visit the U.S. Department of Energy – Solar Lighting Guide.
Learn more: Printed circuit board
Frequently Asked Questions
Q: What battery does this solar flame light circuit board require?
A: This circuit board is designed for a 1.2V Ni-MH rechargeable button battery. The battery is not included with the board and must be purchased separately. The board charges the battery via a compatible 2V / <0.4W solar panel (also sold separately).
Q: Does the flame effect activate automatically, or do I need to switch it on manually?
A: The board features an automatic night-sensing function — it detects ambient light levels and switches on the flame-beating LED pattern at dusk, then turns off at dawn. No manual intervention is required.
Q: Can I use this board to replace a controller in an existing solar candle or garden light?
A: Yes! This board is a popular choice for DIY repairs and replacements. As long as your existing lamp housing accommodates a 2V solar panel input and a 1.2V Ni-MH battery, this 80.8 × 11.8 mm board should integrate seamlessly. Always verify dimensions before purchase.
Q: How many boards do I receive per order?
A: Boards are available in multi-pack options (such as 1, 5, 10, 15, or 20 units). Please select your desired quantity from the product variants before adding to your cart.
