SKKT Thyristor Diode Module – High-Power Rectifier for Industrial Applications
The SKKT Thyristor Diode Module is a robust, high-performance rectifier module engineered for demanding industrial power electronics. Available in a wide range of current ratings (42A through 330A) and voltage ratings up to 1600V, this module delivers reliable switching performance for AC/DC motor control, UPS systems, industrial heating, frequency converters, dimming circuits, and motor soft-start applications.
Made in Mainland China.
Key Features
- Wide Current Range: Available in SKKT 42, 57, 72, 92, 106, 122, 132, 162, 172, 215, 250, and 330 variants to suit virtually any load requirement
- High Voltage Rating: Max forward/reverse voltage up to 1600V; max forward/reverse current up to 500A
- Operating Voltage: 220V nominal
- Type: Rectifier Diode (Thyristor module configuration)
- Condition: Brand new
- Customizable: Custom configurations available — contact customer service for bulk or special orders
- High-Concern Chemicals: None
Typical Applications
- AC and DC motor control & static reactive power compensation
- All types of rectifier power supplies
- Electric welding machines
- Industrial heating control systems
- Frequency converters (Variable Frequency Drives)
- Dimming circuits
- UPS (Uninterruptible Power Supply) systems
- Contactless switches
- Battery charge and discharge applications
- Motor soft-start circuits
Important Selection & Installation Notes
1. Module Selection & Current Margin
The current rating marked on the module is the average on-state value, not the long-term effective RMS operating value. Always leave sufficient margin based on your actual working environment:
- Resistive loads: Apply a 2–2.5× margin — Actual Current (A) × 2 (to 2.5) = Required Module Nominal Current (A)
- Inductive loads: Apply a 6–7× margin — Actual Current (A) × 6 (to 7) = Required Module Nominal Current (A)
2. Heat Sink Configuration
When the actual operating current exceeds 5A, a properly rated heat sink must be installed to ensure safe and reliable operation and to prevent thermal runaway.
3. Stock & Bulk Orders
Standard models are held in stock and available for immediate dispatch. For bulk orders, please contact customer service with your required quantity to confirm lead times and availability.
Specifications Summary
| Parameter | Value |
|---|---|
| Module Type | Thyristor / Rectifier Diode |
| Series | SKKT 42 / 57 / 72 / 92 / 106 / 122 / 132 / 162 / 172 / 215 / 250 / 330 (E / 16E) |
| Max Forward Voltage | 1600V |
| Max Reverse Voltage | 1600V |
| Max Forward Current | 500A |
| Max Reverse Current | 500A |
| Operating Voltage | 220V |
| Condition | New |
| Origin | Mainland China |
