Single Channel PWM Electronic Relay Switch – RC Light Controller
Take full control of your RC model's lighting and accessories with this compact, reliable Single Channel PWM Electronic Relay Switch. Designed for use with standard RC receivers, this relay switch responds to PWM pulse signals (900–2100µs) to switch connected devices on or off — perfect for controlling LED lights, servos, and other accessories on your RC car, boat, plane, or drone.
Made in Mainland China.
Key Features
- Wide Compatibility: Works with any standard RC receiver that outputs a 3–5V PWM pulse signal in the 900–2100µs range.
- High Switching Capacity: Handles up to 10A at 50VDC or 10A at 250VAC — capable of driving a variety of RC accessories and lighting setups.
- Broad Power Input: Receiver power supply operates at DC 4.8V–8.4V, compatible with most RC battery packs including 2S LiPo and NiMH configurations.
- Single Channel Control: Dedicated single-channel design for straightforward, reliable switching without complex setup.
- Compact & Lightweight: Designed to fit neatly into RC model chassis and enclosures without adding unnecessary bulk or weight.
- Easy Integration: Plug-and-play connection to your RC receiver — no soldering required for the signal side.
Specifications
| Switching Voltage (DC) | 50V DC (max) |
| Switching Voltage (AC) | 250V AC (max) |
| Switching Current | 10A (max) |
| PWM Signal | 3–5V high-level, 900–2100µs pulse width |
| Power Supply Voltage | DC 4.8V – 8.4V |
What's in the Box
- 1x Single Channel PWM Electronic Relay Switch
Notes
- Due to lighting and screen differences, the item's color may appear slightly different from product images.
- Please allow 1mm–1cm variance due to manual measurement.
For general electrical safety guidelines related to low-voltage electronics, visit the U.S. Consumer Product Safety Commission (CPSC) Electrical Safety Guide.
Frequently Asked Questions
Q: What RC receivers is this PWM relay switch compatible with?
A: This relay switch is compatible with any standard RC receiver that outputs a 3–5V PWM pulse width signal in the 900–2100µs range. This covers the vast majority of RC receivers used in cars, boats, aircraft, and drones.
Q: Can I use this relay switch to control RC LED lights?
A: Yes! This is one of the most popular uses for this switch. It allows you to toggle LED lighting systems on your RC model using a spare channel on your transmitter, making it ideal for scale lighting effects and functional headlights or taillights.
Q: What battery types are compatible with the 4.8V–8.4V input range?
A: The 4.8V–8.4V input range is compatible with standard 4-cell NiMH/NiCd packs (4.8V), 5-cell NiMH/NiCd packs (6V), and 2S LiPo battery packs (7.4V nominal / 8.4V fully charged) — covering most common RC power setups.
Q: Is any soldering required to install this relay switch?
A: The signal side connects directly to your RC receiver via a standard servo connector — no soldering needed there. However, the switching terminals (where you connect the device being controlled, such as LED strips) may require soldering or use of screw terminals depending on your wiring setup.
