RTP 200W High-Power Planar Thick Film Non-Inductive Resistor
Engineered for demanding electronics applications, the RTP 200W Planar Thick Film Non-Inductive Resistor delivers exceptional performance in high-power, high-frequency, and pulse equalization circuits. Available in a wide range of resistance values — 1Ω, 5Ω, 10Ω, 50Ω, 100Ω, 150Ω, and 1KΩ — this resistor is the go-to choice for engineers and hobbyists who require precision, stability, and reliability.
Key Features
- 200W Power Rating: Handles high-power loads with ease, making it ideal for power electronics and RF applications.
- Non-Inductive Design: Planar thick film construction minimizes inductance, ensuring accurate performance at high frequencies.
- Wide Resistance Range: Available in 1R, 5R, 10R, 50Ω, 100R, 150Ω, and 1KΩ to suit a variety of circuit requirements.
- High-Frequency Pulse Equalization: Optimized for pulse and high-frequency signal equalization tasks in professional-grade circuits.
- Planar Thick Film Technology: Provides consistent resistance values, excellent thermal stability, and long service life.
- Compact, Rugged Construction: Designed for robust performance in both industrial and laboratory environments.
Specifications
- Power Rating: 200W
- Resistance Values Available: 1Ω, 5Ω, 10Ω, 50Ω, 100Ω, 150Ω, 1KΩ
- Type: Planar Thick Film, Non-Inductive
- Application: High-power, high-frequency, pulse equalization circuits
- High-Concern Chemical: None
- Country of Origin: Made in Mainland China
Applications
- RF and microwave power circuits
- Pulse equalization networks
- Power supply and load testing
- High-frequency signal conditioning
- Industrial and laboratory electronics
- Dummy load and termination resistor applications
For further guidance on safe handling of electronic components and best practices in circuit design, visit the OSHA Electrical Safety resource.
Frequently Asked Questions
Q: What does "non-inductive" mean for this thick film resistor?
A: A non-inductive resistor is constructed in a way that minimizes parasitic inductance — meaning it behaves as a pure resistance even at very high frequencies. This makes the RTP 200W planar thick film resistor ideal for RF circuits, pulse applications, and high-frequency signal equalization where any stray inductance would distort performance.
Q: What resistance values are available for the RTP 200W thick film resistor?
A: This high-power non-inductive resistor is available in 1Ω (1R), 5Ω (5R), 10Ω (10R), 50Ω (50 ohms), 100Ω (100R), 150Ω (150 ohm), and 1KΩ (1K), giving you flexibility across a broad range of circuit design requirements.
Q: Can this 200W resistor be used as a dummy load?
A: Yes. With its 200W power handling capability and non-inductive planar thick film design, this resistor is well-suited for use as a dummy load in RF transmitter testing, power supply evaluation, and amplifier load applications.
Q: Is this resistor suitable for industrial applications?
A: Absolutely. The RTP 200W planar thick film non-inductive resistor is designed for robust performance in both industrial and laboratory environments, offering excellent thermal stability, consistent resistance values, and long-term reliability under demanding operating conditions.
