RI80 Glass Glaze Film High Voltage Resistor 20W 50W Non-Inductive
RI80 Glass Glaze Film High Voltage Resistor 20W 50W Non-Inductive
RI80 Red Glass Glaze Film High Voltage Resistor — 20W / 50W, Non-Inductive
The RI80 Series Glass Glaze Film Resistor is a premium, non-inductive high-voltage resistor designed for demanding electronic applications. Available in both 20W and 50W power ratings, this resistor covers an extensive resistance value range — from 1KΩ up to 500MΩ — making it an exceptionally versatile component for power supplies, voltage dividers, high-voltage measurement circuits, and precision instrumentation.
Encased in a distinctive red glass glaze film body, the RI80 offers superior stability, excellent heat dissipation, and reliable performance under high-voltage conditions. Its non-inductive design makes it ideal for high-frequency and pulse applications where inductance would otherwise introduce unwanted interference.
Key Features
- Series: RI80 Red Glass Glaze Film Resistor
- Power Ratings: 20W and 50W options available
- Resistance Range: 1KΩ, 20KΩ, 30MΩ, 50KΩ, 200MΩ, 300KΩ, 500MΩ and more
- Non-Inductive Construction: Minimizes reactive interference in high-frequency circuits
- Glass Glaze Film Coating: Provides excellent thermal stability and environmental protection
- High Voltage Rated: Engineered to withstand elevated operating voltages safely
- Wide Application Range: Suitable for power electronics, HV measurement, voltage dividers, pulse circuits, and more
- Durable Build: Robust construction ensures long service life even in demanding conditions
Specifications
| Parameter | Details |
|---|---|
| Series | RI80 |
| Type | Glass Glaze Film, Non-Inductive |
| Power Rating | 20W / 50W |
| Resistance Values | 1KΩ, 20KΩ, 30MΩ, 50KΩ, 200MΩ, 300KΩ, 500MΩ |
| Application | High Voltage Circuits, Power Supplies, Measurement |
| Country of Origin | Made in Mainland China |
| Brand | BOKON INTL |
Typical Applications
- High-voltage power supply circuits
- Voltage divider networks
- Pulse and surge protection circuits
- High-frequency electronic equipment
- Precision measurement and instrumentation
- Industrial and laboratory electronics
For further reference on resistor standards and electronic component safety guidelines, visit the National Institute of Standards and Technology (NIST) Electronics Resources.
Frequently Asked Questions
Q: What does "non-inductive" mean for the RI80 glass glaze film resistor?
A: A non-inductive resistor is wound or constructed in a way that cancels out any inductance. This is critical in high-frequency, pulse, or RF circuits where even small inductance values could cause signal distortion or energy losses. The RI80 non-inductive design ensures purely resistive behavior across a wide frequency range.
Q: What resistance values are available for the RI80 20W and 50W resistors?
A: The RI80 series covers a broad resistance range including 1KΩ, 20KΩ, 50KΩ, 300KΩ, 30MΩ, 200MΩ, and 500MΩ, among others. This wide selection makes the RI80 suitable for everything from moderate voltage division to ultra-high-voltage measurement applications.
Q: Is the RI80 glass glaze resistor suitable for outdoor or harsh environments?
A: The glass glaze film coating provides a high degree of environmental protection against moisture, dust, and temperature fluctuations, making the RI80 a reliable choice for both indoor industrial equipment and applications exposed to varying environmental conditions. Always verify the specific operating temperature range for your selected resistance value and power rating.
Q: What is the difference between the 20W and 50W versions of the RI80?
A: The power rating (20W vs. 50W) indicates how much electrical power the resistor can continuously dissipate as heat without damage. The 50W version is physically larger and better suited for higher-current or higher-power applications, while the 20W version is more compact for space-constrained designs.
