Asia-Teco RFID Touch Keypad Access Control System – Model T9-EM
Upgrade your door security with the Asia-Teco T9-EM RFID Access Control Keypad — a sleek, multi-mode entry system supporting up to 2,000 users. Whether you manage an office, apartment building, warehouse, or small business, this 125KHz touch keypad delivers reliable, flexible access management at an outstanding value. Made in Mainland China.
Why Choose the T9-EM?
- Triple Identification Modes: Unlock via RFID card, PIN password, or a combined card + password method for added security layers.
- High Capacity: Stores up to 2,000 unique users — ideal for multi-tenant buildings or busy workplaces.
- Blue Backlit Touch Panel: Elegant, easy-to-read touchscreen keypad with a glowing blue backlight for effortless use day or night.
- 125KHz RFID Reading: Compatible with standard EM ID cards and key fobs; reads at a practical 2–6 cm distance.
- Wiegand WG26/34 I/O: Seamlessly integrates with existing access control infrastructure, door controllers, and third-party readers.
- Adjustable Door Delay: Customize door open time from 0 to 99 seconds to suit your specific entry needs.
- Wired Doorbell Support: Built-in external wired doorbell connection for complete entry-point management.
- Master Card Management: Easily enroll or delete users using a master card — no software required.
- Durable ABS Shell: One-piece fire-retardant, impact-resistant, and wear-resistant ABS high-quality material construction.
- Wide Operating Range: Performs reliably from -40°C to 60°C and in humidity of 10%–90%, making it suitable for most indoor environments.
Technical Specifications
| Model | T9-EM |
| Brand | Asia-Teco |
| User Capacity | 2,000 Users |
| Working Frequency | 125KHz |
| Card Type | EM ID Compatible Cards |
| Card Reading Distance | 2–6 cm |
| Identification Methods | Card / Password / Card + Password |
| Wiegand Signal | WG26/34 Input/Output |
| Backlight | Blue Backlight Touch Panel |
| Doorbell | External Wired Doorbell Connection |
| Working Voltage | DC 12V |
| Working Current | ≤ 30mA |
| Door Delay Time | 0–99 Seconds |
| Working Temperature | -40°C ~ 60°C |
| Working Humidity | 10%–90% |
| Product Size | 140 × 69 × 17 mm |
| Material | ABS (Fire Retardant, Impact Resistant) |
| Waterproof Rating | Not Rated for Outdoor Wet Conditions |
| Country of Origin | Made in Mainland China |
Easy Integration & Setup
The T9-EM supports standard Wiegand WG26/34 protocols, making integration with most access control panels and electric locks straightforward. The master card setup means administrators can manage access credentials quickly without specialized software. Configure door delay times from 0 to 99 seconds and set up multiple authentication methods to match your security policy.
Who Is This For?
The Asia-Teco T9-EM is a great fit for:
- Small to mid-size offices requiring keyless entry
- Apartment buildings and condos with multiple residents
- Warehouses, storage facilities, and server rooms
- Schools, gyms, and community centers
- Retail back-office or stockroom access control
For general guidance on physical access control best practices, visit the Cybersecurity and Infrastructure Security Agency (CISA). For consumer product safety standards, refer to the U.S. Consumer Product Safety Commission (CPSC).
Frequently Asked Questions
Q: What types of RFID cards are compatible with the T9-EM access control keypad?
A: The Asia-Teco T9-EM operates at 125KHz and is compatible with standard EM ID cards and key fobs. It supports EM ID-compatible cards with a reading distance of 2–6 cm.
Q: Can this RFID keypad be used alongside an existing access control system?
A: Yes. The T9-EM features Wiegand WG26/34 input/output, which is one of the most widely used protocols in the access control industry. This allows it to integrate seamlessly with most door controllers, panels, and electric locks that support the Wiegand standard.
Q: How many users can the T9-EM access control system support?
A: The T9-EM can store up to 2,000 unique users, making it suitable for offices, apartment buildings, schools, and other multi-user environments.
Q: Is the T9-EM keypad suitable for outdoor installation?
A: The T9-EM does not carry a waterproof rating, so it is best suited for covered or indoor installations. For outdoor use, ensure the device is protected from direct rain or moisture exposure.
Q: How is the access control keypad powered?
A: The T9-EM operates on DC 12V with a working current of ≤30mA, making it energy-efficient and compatible with standard access control power supplies.
