RFID Biometric Fingerprint Access Control & Attendance Machine
RFID Biometric Fingerprint Access Control & Attendance Machine
Asia-Teco D9 RFID Biometric Fingerprint Access Control & Time Attendance System
The Asia-Teco D9 is a powerful, all-in-one access control and time attendance terminal that combines fingerprint biometrics, RFID card reading (125KHz & 13.56MHz), and PIN keypad entry into a single compact device. Ideal for offices, factories, hotels, schools, and any facility requiring secure, reliable entry management and accurate staff attendance tracking.
Made in Mainland China.
Three Flexible Verification Methods
Your team can check in and gain entry using any of three convenient methods:
- Fingerprint Recognition — Fast, accurate biometric identification; stores up to 1,000 fingerprint templates
- RFID Card — Supports both 125KHz (EM) and 13.56MHz card formats; capacity for 1,000 cards
- PIN / Password — Simple keypad entry for up to 1,000 unique passwords
Key Features
- 📺 2.4-inch TFT Color Screen — Clear, easy-to-read display for intuitive operation
- 🔒 Dual-Frequency RFID — Reads both 125KHz and 13.56MHz cards seamlessly
- 👆 Energy-Saving Fingerprint Sensor — Advanced power management keeps the unit running efficiently
- 💾 USB Flash Drive Transfer — Upload and download attendance data via U-Disk with no network required
- 📋 100,000 Record Capacity — Stores a massive log of time and attendance events
- 🔔 Wiegand 26/34 Input/Output — Compatible with existing access control infrastructure; includes relay output and doorbell button
- 🚨 Tamper Alarm Function — Built-in alarm triggers if the unit is tampered with
- 📝 T9 Input Method — Enter employee names, departments, and schedule info directly on the device
- 🌐 English Language Support — Fully menu-driven in English for ease of use
- ⚡ DC 12V Operation — Standard low-voltage power supply
Dual-Function Use Cases
The D9 operates in two modes, making it a truly versatile security and HR tool:
- Standalone Access Control Keypad — Grant or deny door entry via fingerprint, RFID card, or password, with no PC required.
- Time & Attendance Recorder — Log employee check-in/check-out times and export reports via USB for payroll and HR management.
Technical Specifications
| Model | Asia-Teco D9 |
| RFID Frequency | 125KHz + 13.56MHz |
| Fingerprint Capacity | 1,000 |
| Card Capacity | 1,000 EM Cards |
| Record Capacity | 100,000 Entries |
| Display | 2.4-inch TFT Color Screen |
| Communication | USB Flash Drive (U-Disk) |
| Wiegand | Wiegand 26/34 Input/Output |
| Working Voltage | DC 12V |
| Language | English |
| Origin | Mainland China |
Where to Use It
The Asia-Teco D9 is perfectly suited for entrances and exits at:
- Offices & Corporate Buildings
- Factories & Warehouses
- Hotels & Hospitality Venues
- Schools & Educational Facilities
- Healthcare Clinics & Pharmacies
- Retail Stores & Service Centers
For more information on workplace security and access control standards, visit the OSHA Workplace Safety Resource Center.
Frequently Asked Questions
Q: What RFID card types does the Asia-Teco D9 access control system support?
A: The D9 supports both 125KHz (EM format) and 13.56MHz RFID card frequencies, giving you flexibility to use a wide range of common access cards and key fobs without needing separate readers for different card types.
Q: How do I download attendance records from the time clock recorder?
A: The D9 uses a USB Flash Drive (U-Disk) for data transfer. Simply insert a USB drive into the device, export the attendance records to the drive, and then plug it into your PC to view, process, or import the data into your HR or payroll software — no network or special software installation required on the device itself.
Q: Can the D9 be used as a standalone access control system without a computer?
A: Yes! The Asia-Teco D9 operates fully as a standalone access control terminal. It can manage door entry permissions using fingerprint, RFID card, or PIN without needing to be connected to a PC or network. This makes it easy to deploy in locations without IT infrastructure.
Q: How many users and records can the D9 biometric attendance machine store?
A: The D9 supports up to 1,000 fingerprints, 1,000 RFID cards, and 1,000 PIN passwords. It can store up to 100,000 time attendance records in its onboard memory, making it suitable for small to mid-sized organizations.
Q: Does the fingerprint access control system have a tamper alarm?
A: Yes. The D9 features a built-in tamper alarm function that triggers an alert if someone attempts to physically tamper with or remove the unit, adding an extra layer of security to your premises.
