RFID 13.56MHz USB Numeric Keypad Card Reader – ISO 14443A
Streamline access control, attendance tracking, and card-based authentication with this versatile RFID 13.56MHz USB Numeric Keypad Reader. Supporting the ISO 14443A standard, it reads a wide range of popular contactless IC cards and operates as a true plug-and-play USB HID device — no drivers required. Simply connect via USB and start scanning cards on Windows, Linux, or Android immediately.
Key Features
- No Driver Needed: USB HID (Human Interface Device) interface — works out of the box on most operating systems.
- Wide Card Compatibility: Reads M1 Classic S50, S70, FM1108, MF Plus 4-bit, NTAG213, NTAG215, NTAG216, DESFire, Ultralight, and other ISO 14443A-compliant cards.
- Fast Read Speed: Card read time under 100ms for quick, efficient operation.
- Numeric Keypad Included: Integrated keypad for PIN entry, combining card and code-based verification in a single compact unit.
- Broad OS Support: Compatible with Windows XP, WinCE, Windows 7, Windows 10, Linux, and Android.
- CE Certified: Meets CE certification standards for quality and safety compliance.
- Compact & Desk-Ready: Slim 135 × 85 × 28 mm form factor fits neatly on any desk or counter.
Technical Specifications
| Frequency | 13.56 MHz (ISO 14443A) |
| Supported Card Types | M1 S50, S70, NTAG213, NTAG215, NTAG216, DESFire, Ultralight, FM1108, MF Plus 4-bit |
| Read Distance | 0–5 cm |
| Read Time | < 100ms |
| Interface | USB HID (Plug & Play, no driver required) |
| Working Voltage | 5V (USB powered) |
| Working Current | 100 mA |
| Dimensions | 135 × 85 × 28 mm |
| OS Support | Windows XP / WinCE / Win 7 / Win 10, Linux, Android |
| Certification | CE |
| Country of Origin | Made in Mainland China |
IC Reader Output Format Reference
| Chip Type | Serial Number (Example) | Reader Output |
|---|---|---|
| M1 Classic S50, S70, FM1108, MF Plus 4-bit | 87:80:72:99 | 2574418055 (Decimal) / 99 72 80 87 (Hex) |
| NTAG213/215/216, DESFire, Ultralight | 04:CA:2E:82:5D:5A:80 | 2184104452 (Decimal) / 82 2E CA 04 (Hex) |
Ideal Use Cases
- Office and building access control systems
- Employee or student attendance tracking
- Point-of-sale or loyalty card scanning
- IT and developer projects requiring USB card input
- Locker, library, or event check-in management
For more information on RFID technology standards and contactless card security, visit the NIST Guidelines for Securing RFID Systems.
Frequently Asked Questions
Q: Does this RFID USB keypad reader require any special drivers to install?
A: No — this reader uses the USB HID (Human Interface Device) protocol, making it a true plug-and-play device. Simply connect it to a USB port on your computer or Android device and it will be recognized automatically. No additional drivers are needed on Windows XP, Windows 7, Windows 10, Linux, or Android.
Q: What types of RFID cards are compatible with this 13.56MHz reader?
A: This reader supports all ISO 14443A standard contactless cards, including Mifare Classic M1 S50 and S70, FM1108, MF Plus 4-bit, NTAG213, NTAG215, NTAG216, DESFire, and Ultralight chips. It outputs the card's UID both in decimal and hexadecimal format for easy integration with software systems.
Q: What is the maximum card reading distance for this RFID keypad reader?
A: The effective reading distance is 0 to 5 cm. For best results, hold the card within a few centimeters of the reader's scanning area. The read time is under 100ms, ensuring a fast and responsive experience.
Q: Can this RFID reader be used for both card scanning and PIN entry?
A: Yes. The integrated numeric keypad allows users to enter a PIN code in addition to scanning an RFID card, making it suitable for two-factor verification setups where both a card and a numeric code are required for access.
