Metal RFID Keypad Access Controller – 125KHz, 1000 Users, Backlit Keypad
Take control of who enters your property with the Asia-Teco A07 Metal Case RFID Keypad Access Controller. Designed for single-door entry management, this robust unit supports up to 1,000 users and offers three convenient access methods: PIN code, 125KHz RFID card (EM card), or a combination of both — giving you versatile, reliable security at your fingertips.
The heavy-duty metal enclosure makes this controller ideal for both indoor and outdoor installations, standing up to everyday wear and environmental demands. The backlit keypad ensures clear visibility in low-light or nighttime conditions, so authorized users can always gain access quickly and confidently.
Key Features
- Supports up to 1,000 users — perfect for offices, warehouses, apartments, and more
- Dual access methods: PIN code entry, 125KHz RFID (EM) card, or both combined
- Backlit keypad — fully functional in dark or low-light environments
- Durable metal housing — built for long-term indoor and outdoor use
- Simple programming — easy setup and user management with no specialist tools required
- Independent control — operates as a standalone unit, no additional PC or software required
- Wide operating temperature range: -20°C to +60°C
- Max card reading distance: up to 6.5 cm
- Compact and discreet: 115 × 72 × 40 mm footprint
Technical Specifications
| Brand | Asia-Teco |
| Model | A07 |
| Card Type | EM Card, 125KHz |
| Card Reading Distance | Max 6.5 cm |
| User Capacity | 1,000 Users |
| Operating Voltage | 12V DC |
| Operating Temperature | -20°C to +60°C |
| Operating Humidity | 10% – 90% RH |
| Dimensions | 115 × 72 × 40 mm |
| Weight | 422 g |
| Country of Origin | Made in Mainland China |
Ideal Applications
Whether you're securing a small business, managing access to a multi-unit residential building, or controlling entry to a restricted area, the Asia-Teco A07 is a cost-effective and dependable solution. Its standalone design means no internet connection or external controller is needed — just wire it up and go.
For further guidance on physical access control best practices and security standards, visit the OSHA Workplace Security Resources.
Frequently Asked Questions
Q: How many users can the Asia-Teco A07 RFID access controller support?
A: The Asia-Teco A07 metal keypad access controller supports up to 1,000 individual users, each assignable via PIN code, RFID card, or a combination of both. This makes it suitable for small to medium-sized commercial or residential installations.
Q: What type of RFID cards are compatible with this access controller?
A: This controller is compatible with 125KHz EM cards, which are widely available and commonly used in access control systems. The maximum card reading distance is up to 6.5 cm.
Q: Can this keypad access controller be used outdoors?
A: Yes. The durable metal housing and wide operating temperature range (-20°C to +60°C) make the A07 suitable for both indoor and outdoor installation. It is designed to withstand varying environmental conditions.
Q: Does this unit require a computer or software to program?
A: No. The Asia-Teco A07 is a standalone, independent access control device. Programming is done directly on the keypad — no PC, software, or internet connection is required, making setup straightforward and hassle-free.
Q: What power supply does the A07 access controller need?
A: The controller operates on a 12V DC power supply. Please ensure your installation uses a stable 12V DC source for optimal performance and reliability.
