Take your electronics projects to the next level with the M181 LCR Bridge Tester Module — a high-precision, fully assembled (welded) DIY kit designed for hobbyists, engineers, and electronics enthusiasts. Powered via USB (DC 5V), this compact meter accurately measures inductance, capacitance, and resistance across wide ranges, making it an indispensable bench tool for component testing and circuit development.
Key Features
- USB Powered (DC 5V): Convenient power via any standard USB port — no batteries required.
- Full Automatic Range: Automatically selects the optimal measurement range for fast, accurate readings.
- ~1% Accuracy: Delivers consistent, reliable measurements you can trust for component sorting and circuit design.
- Display Freeze Function: Lock the current reading on screen for easy recording and analysis.
- Serial Output: Measurement results are output in serial format for logging or interfacing with a PC.
-
Wide Measurement Ranges:
- Resistance: 0.1 Ω – 10 MΩ
- Capacitance: 1 pF – 10,000 µF
- Inductance: 1 µH – 20 H
- Pre-Welded DIY Kit: Comes fully soldered and ready to use — ideal for beginners and experienced makers alike.
Specifications
| Power Supply | USB, DC 5V |
| Measurement Accuracy | ~1% |
| Range Selection | Full Automatic |
| Resistance Range | 0.1 Ω – 10 MΩ |
| Capacitance Range | 1 pF – 10,000 µF |
| Inductance Range | 1 µH – 20 H |
| Output | Serial data output |
| Country of Origin | Made in Mainland China |
What's in the Box?
- 1 × M181 LCR Bridge Tester Module (Pre-Welded DIY Kit)
Notes
- Due to differences in lighting and screen calibration, the item's color may vary slightly from product images.
- Please allow 1 mm – 1 cm variance due to manual measurement.
For more information on electronics safety and best practices for DIY electronic kits, visit the U.S. Consumer Product Safety Commission (CPSC).
Frequently Asked Questions
Q: What does the M181 LCR Bridge Tester Module measure?
A: The M181 LCR Bridge Tester Module measures three key passive component values: inductance (1 µH – 20 H), capacitance (1 pF – 10,000 µF), and resistance (0.1 Ω – 10 MΩ). It is ideal for sorting components, verifying component values, and supporting electronics DIY projects and circuit development.
Q: Does the M181 LCR meter come fully assembled or do I need to solder it?
A: This kit comes pre-welded (fully soldered), meaning no additional soldering is required. Simply power it via USB and it is ready to use right out of the box.
Q: How is the M181 LCR tester powered?
A: The M181 LCR Bridge Tester is powered via a standard USB port (DC 5V), making it easy to use with a laptop, desktop computer, USB hub, or USB wall adapter — no proprietary power supply needed.
Q: Can I log measurement data from this LCR tester to a computer?
A: Yes! The M181 module features a serial data output function, allowing you to transmit measurement results to a PC for data logging, analysis, or integration with other electronics systems.
