M181 LCR Bridge Tester – High Precision LCR Meter DIY Kit
M181 LCR Bridge Tester – High Precision LCR Meter DIY Kit
M181 LCR Bridge Tester Module – High Precision Inductance, Capacitance & Resistance Meter DIY Kit
Take your electronics projects to the next level with the M181 LCR Bridge Tester Module — a high-precision, fully assembled DIY kit designed for hobbyists, engineers, and electronics enthusiasts. Powered via USB (DC 5V), this compact module accurately measures inductance, capacitance, and resistance across an impressively wide range, all with approximately 1% accuracy. Whether you're sorting components, debugging circuits, or building test equipment, the M181 delivers reliable readings at a glance.
Key Features
- USB Power Supply (DC 5V): Powers conveniently from any standard USB port — no dedicated power adapter needed.
- Full Automatic Range: No manual range switching required; the module auto-selects the optimal measurement range.
- ~1% Accuracy: Delivers dependable, repeatable measurements suitable for component sorting and circuit verification.
- Display Freeze Function: Lock the current reading on-screen for easy recording and hands-free reference.
- Serial Data Output: Measurement results are output serially, making it easy to log data or integrate with a microcontroller/PC.
-
Wide Measurement Ranges:
- Resistance: 0.1 Ω – 10 MΩ
- Capacitance: 1 pF – 10,000 µF
- Inductance: 1 µH – 20 H
- Welded DIY Kit: Comes pre-soldered and ready to use — ideal for those who want a finished, functional module right out of the box.
What's in the Box?
- 1× M181 LCR Bridge Tester / Capacitance Meter (fully welded)
Specifications at a Glance
| Power Input | USB DC 5V |
| Accuracy | ~1% |
| Resistance Range | 0.1 Ω – 10 MΩ |
| Capacitance Range | 1 pF – 10,000 µF |
| Inductance Range | 1 µH – 20 H |
| Range Selection | Full Automatic |
| Data Output | Serial |
| Country of Origin | Made in Mainland China |
Important Notes
- Due to lighting and screen variations, the item's color may appear slightly different from product images.
- Please allow 1 mm – 1 cm differences due to manual measurement.
For best practices in electronics safety and component handling, refer to the U.S. Consumer Product Safety Commission – Electrical Safety guidelines.
Frequently Asked Questions
Q: What does the M181 LCR Bridge Tester measure?
A: The M181 LCR Bridge Tester measures three core passive component parameters: Inductance (1 µH – 20 H), Capacitance (1 pF – 10,000 µF), and Resistance (0.1 Ω – 10 MΩ). It's ideal for verifying and sorting resistors, capacitors, and inductors in electronics projects.
Q: Does the M181 require any soldering or assembly?
A: No. This kit is described as "welded" (pre-soldered), meaning the module comes fully assembled and ready to use. Simply connect it to a USB 5V power source and start measuring your components.
Q: How is the M181 powered?
A: The M181 LCR meter is powered via a standard USB connection at DC 5V, making it compatible with phone chargers, power banks, computer USB ports, and other common 5V USB sources.
Q: Can I log the measurement data to a computer?
A: Yes. The M181 outputs measurement results serially, so you can connect it to a microcontroller (e.g., Arduino) or a PC with a serial interface to record and log your readings automatically.
Q: Is the measurement range selection manual or automatic?
A: The M181 features full automatic range selection — it intelligently detects the component being measured and selects the appropriate range without any manual input from the user.
