LK6 125KHz RFID Touch Keypad Door Access Control System
LK6 125KHz RFID Touch Keypad Door Access Control System
LK6 RFID Touch Keypad Door Access Control System — Smart, Secure & Reliable
Upgrade your entry security with the Asia-Teco LK6 RFID Door Access Control System. Featuring a sleek touch keypad design and 125KHz EM card compatibility, this smart controller lets you manage access for up to 800 users with ease. Whether you're securing an office, apartment, warehouse, or any controlled-entry space, the LK6 delivers fast, flexible, and dependable access management.
Key Features
- Triple Access Modes: Unlock via RFID card, PIN password, or a combination of both for maximum flexibility and security.
- Large User Capacity: Stores up to 800 RFID cards and 800 individual passwords — ideal for small to mid-size facilities.
- Lightning-Fast Identification: Card recognition in under 1 second ensures smooth, uninterrupted entry flow.
- Backlit Touch Keypad: Illuminated keys allow easy operation even in low-light conditions.
- Ultra-Low Power Consumption: Standby current under 60mA keeps energy costs to a minimum.
- Independent User Passwords: Each user can set and modify their own PIN for added convenience and security.
- Remote Card Deletion: Lost a card? Quickly deactivate it via the keypad to maintain security without hassle.
- Wiegand Interface: Compatible as a standalone controller or as a reader connected to an external controller.
- Wide Environmental Tolerance: Operates reliably in temperatures from 0°C to 55°C and humidity from 40%RH to 90%RH.
- Fail-Safe Mode with Signal: Designed for reliable operation even during power or system anomalies.
Technical Specifications
| Model | LK6 |
| Card Type | 125KHz RFID / EM Card / Mifare Card |
| User Capacity | 800 Cards + 800 Passwords |
| Working Voltage | 12V DC |
| Open Lock Current | 1.5A |
| Identification Speed | ≤1 second |
| Open Modes | Card / Password / Card + Password |
| Read Distance | 0–10 cm |
| Working Temperature | 0°C – 55°C |
| Relative Humidity | 40%RH – 90%RH |
| Wiegand | Supported |
| Dimensions | 123 × 70 × 17 mm |
| Security Mode | Fail Safe with Signal |
Why Choose the LK6 Access Controller?
The Asia-Teco LK6 is built for real-world security demands. Its compact, modern profile fits standard door frames cleanly, while its intuitive touch interface means minimal training for users. Whether you're managing a team of 10 or hundreds, the LK6's 800-user capacity and flexible unlocking modes make it one of the most versatile standalone access controllers available. Made in Mainland China.
For best practices on physical access control and building security, refer to the Cybersecurity & Infrastructure Security Agency guidelines. You can also explore electronic security standards via the National Institute of Standards and Technology (NIST).
Frequently Asked Questions
Q: What types of cards are compatible with the LK6 RFID access control system?
A: The LK6 is compatible with 125KHz RFID EM cards and Mifare cards. It does not support 13.56MHz high-frequency cards. Always verify your existing card frequency before purchase.
Q: Can multiple users have their own individual PINs on the LK6?
A: Yes! The LK6 supports up to 800 independent user passwords. Each user can set and modify their own PIN code directly from the touch keypad, making user management straightforward and secure.
Q: What happens if a card is lost or stolen?
A: You can easily delete a lost or stolen card directly from the keypad without needing any additional software or hardware. This immediately revokes access for that card, maintaining the integrity of your security system.
Q: What power supply does the LK6 access controller require?
A: The LK6 operates on a standard 12V DC power supply with an open lock current of 1.5A. It is not included in the package, so please ensure you have a compatible power adapter available.
Q: Is the LK6 suitable for outdoor installation?
A: The LK6 can operate in temperatures from 0°C to 55°C and humidity up to 90%RH, making it suitable for semi-outdoor or covered entry points. For fully exposed outdoor environments, additional weatherproofing measures are recommended.
