JCSMARTS BLE Online Wall Controller – Hotel Access System

JCSMARTS Online System BLE Wall Controller — Smart Hotel Access Management

Take full control of your property's entry points with the JCSMARTS Online System Wall Controller — a compact, versatile access management device engineered for hotels, commercial properties, and secure facilities. Whether you're managing turnstiles, barriers, electromagnetic locks, or electromechanical locks, this intelligent controller integrates seamlessly with NC and NO wiring schemes for a truly flexible installation.

Key Features

• Multiple Access Methods: Grant entry via keycard, permanent card, Bluetooth mobile app, or PIN password — giving staff and guests a smooth, frictionless experience.
• Remote Access via HTLock App: Just like an online smart lock, this controller can be opened remotely through the HTLock platform, keeping your team in control at all times.
• BLE (Bluetooth Low Energy) Connectivity: Reliable short-range wireless communication for fast, energy-efficient operation.
• Flexible Mounting Options: Install on the front or back of a door (a push-button opens from the opposite side), or mount on both sides to capture passage data in both directions.
• Fire Alarm Integration: When installed on an evacuation route, the controller can be integrated into your fire alarm system to automatically disengage during an emergency.
• Durable Construction: Built with a robust plastic body and steel chassis for long-lasting reliability in high-traffic environments.
• Compact Form Factor: Slim 100 × 60 × 12 mm profile fits discreetly on any wall or door frame.

Application Examples

• Electromagnetic Door Lock / Wicket Gate: Control guest and staff passages, with reception desk override via push-button.
• Hotel Turnstile: Secure access to restricted or premium areas of your property.
• Parking Barrier: Manage vehicle entry with card, app, or code authentication.
• Elevator Floor Controller: Restrict floor access so guests must swipe a card, enter a code, or use the mobile app to unlock their designated floor button.

Technical Specifications

⚠️ Important: This controller requires an external 12 V DC power supply (sold separately). Ensure your installation site has a compatible power source before purchasing.

For guidance on best practices for access control system installation, visit the OSHA Electrical Safety Guidelines to ensure your setup complies with workplace safety standards.

Frequently Asked Questions

Q: What types of locks and devices are compatible with the JCSMARTS Online Wall Controller?

A: The JCSMARTS wall controller is compatible with a wide range of access control hardware, including electromagnetic locks, classic electromechanical locks, turnstiles, parking barriers, and any other device wired according to NC (normally closed) or NO (normally open) schemes.

Q: Does the Online System Wall Controller require an internet connection?

A: The controller operates via BLE (Bluetooth Low Energy) for local wireless communication and integrates with the HTLock online platform for remote management. An external 12 V DC power supply is required; internet connectivity is needed for remote HTLock access features.

Q: Can the controller be mounted on both sides of a door?

A: Yes. You can mount the JCSMARTS wall controller on both sides of a door simultaneously. This configuration allows the system to log passage data in both directions, providing comprehensive entry and exit tracking for your property.

Q: Is the wall controller suitable for fire evacuation routes?

A: Yes, but when installed on an evacuation route, the controller must be integrated into the building's fire alarm system. This ensures that the access control device is automatically disabled when a fire alarm is triggered, allowing safe and unobstructed egress.
