IP68 WiFi Smart Keypad – RFID Tuya App Door Access Control
IP68 WiFi Smart Keypad – RFID Tuya App Door Access Control
LUCKING DOOR S601-WiFi Outdoor Smart Access Control Keypad
Take command of your entryway with the LUCKING DOOR S601-WiFi All-Metal Smart Keypad — a rugged, weatherproof access controller built for demanding outdoor environments. Engineered with an IP68-rated aluminum alloy shell and metal key buttons, this unit is fully sealed against dust and water immersion, making it equally at home on a gate, garage, or commercial entrance. Manage up to 2,000 users remotely via the Tuya Smart App, issue temporary passwords on the fly, and monitor access activity from anywhere in the world.
Made in Mainland China.
Multiple Ways to Unlock
- 📱 Tuya App (WiFi) — remote unlock from your smartphone, anywhere
- 🔑 125 kHz RFID Card (13.56 MHz MF card optional) — fast <0.1 s swipe recognition
- 🔢 PIN Password — 4-digit individual codes, user-modifiable
- 🃏 Card + Password — dual-factor combined unlock for extra security
- 📨 Temporary Password — grant time-limited access without issuing a permanent credential
Key Features
- IP68 Waterproof — fully sealed aluminum alloy body with silver-plated metal keys; withstands rain, dust, and submersion
- Large User Capacity — stores up to 2,000 RFID cards and 2,000 PIN codes simultaneously
- Ultra-Low Power — standby current under 50 mA; 12 V DC operation
- Wiegand 26/34 Input & Output — connect an external card reader or use this unit as a reader in a larger access system
- Programmable Lock Release Time — adjustable from 1–255 seconds to suit any door hardware
- Relay Output — NO/NC selectable; Secure and Normal modes supported
- Auxiliary Functions — door-ajar alert, forced-door alarm, shunt, door monitor
- Built-in Buzzer & Bell Button — internal buzzer, alarm/chime siren with programmable siren time
- Tamper Protection — built-in case and back tamper detection with siren and tamper output
- 3 User Levels — Normal User, Secure User, and Master User for tiered access management
- 2 Status / Programming LEDs — clear visual feedback during setup and operation
- Wide Operating Temperature — −25 °C to +55 °C for year-round outdoor reliability
- Tuya Smart Home Platform — compatible with the Tuya ecosystem for seamless smart-home integration
Technical Specifications
| Model | S601EM-W-WiFi.e |
| Dimensions | 120 × 56 × 18 mm |
| Working Voltage | 12 V DC |
| Lock Open Current | 2 A |
| Standby Current | < 50 mA |
| Card Frequency | 125 kHz EM (13.56 MHz MF optional) |
| Read Distance | 1–15 cm |
| Identify Speed | < 0.1 s |
| User Capacity | 2,000 cards + 2,000 passwords |
| Waterproof Rating | IP68 |
| Wiegand | 26/34 Input & Output |
| Smart Platform | Tuya (WiFi) |
| Operating Temperature | −25 °C to +55 °C |
| Shell Material | Aluminum Alloy (All-Metal) |
| Origin | Mainland China |
Why Choose the S601-WiFi?
Whether you're securing a residential gate, a commercial building entrance, or a shared workspace, the S601-WiFi delivers enterprise-grade access control in a compact, weather-resistant package. The Tuya App integration means you're always in control — check who entered, grant temporary access to a guest, or lock down the door remotely — all from your phone.
For general guidance on evaluating electronic security and access control devices for your home or business, visit the U.S. Consumer Product Safety Commission (CPSC).
Frequently Asked Questions
Q: Is this smart keypad truly waterproof for permanent outdoor installation?
A: Yes. The LUCKING DOOR S601-WiFi carries an IP68 waterproof rating, the highest standard for dust-tight and water-immersion protection. Its all-aluminum alloy body and metal keys are designed to withstand continuous outdoor exposure including heavy rain, dust, and extreme temperatures from −25 °C to +55 °C.
Q: How do I manage users and grant remote access with this keypad?
A: The S601-WiFi connects to your home or business WiFi network and integrates with the Tuya Smart App (iOS & Android). From the app you can add or delete users, issue temporary passwords, unlock the door remotely, and view access logs — all in real time from anywhere with an internet connection.
Q: Can this unit be integrated into an existing access control system?
A: Absolutely. The S601-WiFi supports Wiegand 26/34 input and output, allowing it to connect to external card readers or function as a reader within a larger access control infrastructure. It also provides NO/NC relay output and auxiliary modes including door-ajar, forced-door, and door-monitor functions for full system compatibility.
Q: How many users and credentials does this keypad support?
A: The S601-WiFi supports up to 2,000 RFID cards and 2,000 individual PIN codes simultaneously — making it suitable for small businesses, apartment buildings, gyms, and other multi-user environments.
