IP67 Waterproof RFID Touch Keypad Access Control – Zinc Alloy
IP67 Waterproof RFID Touch Keypad Access Control – Zinc Alloy
Zinc Alloy Backlit Touch Access Control Keypad with RFID & Fingerprint
Upgrade your entry points with this sleek, standalone all-in-one access control system from LUCKING DOOR. Built from premium zinc alloy with a durable tempered glass front panel, this keypad combines modern aesthetics with robust security — ideal for high-end office buildings, residential communities, and other public spaces. Made in Mainland China.
Why Choose This Access Control Keypad?
- Triple Unlock Methods: Supports password, 125kHz EM RFID card, and fingerprint recognition for flexible, multi-factor entry management.
- IP67 Waterproof Rating: Fully sealed against dust and water immersion, making it suitable for outdoor and exposed installations in all weather conditions.
- Backlit Touchscreen: Enable or disable the backlight as needed — perfect for low-light environments and nighttime use.
- Fast Recognition: Identifies credentials in ≤0.3 seconds for smooth, uninterrupted access flow.
- Wide Temperature Range: Operates reliably from -40°C to 60°C, ensuring year-round performance in extreme climates.
- Wiegand Output (26-bit to 34-bit): Easily integrates with a wide range of existing access control systems and panels.
- Adjustable Door Relay Time: Set the door open duration anywhere from 1 to 99 seconds to match your security requirements.
- Large User Capacity: Stores up to 1,000 cards and 100 fingerprints for scalable deployment.
- Tamper-Evident Design: Zinc alloy housing with a tamper-evident structure discourages unauthorized tampering.
- Administrator Management: Supports autonomous setup of MasterCard and master code for streamlined administration.
Key Specifications
| Material | Zinc Alloy + Tempered Glass Panel |
| Card Type | 125kHz EM Card |
| Card Capacity | 1,000 cards |
| Fingerprint Capacity | 100 fingerprints |
| Card Reading Distance | 2–5 cm |
| Recognition Speed | ≤ 0.3 seconds |
| Waterproof Rating | IP67 |
| Wiegand Format | 26-bit to 34-bit |
| Door Relay Time | 1–99 seconds (adjustable) |
| Working Voltage | DC 12V |
| Standby Current | ≤ 30mA |
| Dimensions | 86 × 86 × 13 mm |
| Operating Temperature | -40°C to 60°C |
| Humidity Range | 10%–90% |
| Certifications | CE, FCC |
| Model Numbers | TF886 / T886 / TC886 |
| Country of Origin | Made in Mainland China |
⚠️ Important Note on Model TF886: The TF886 Wiegand output supports cards and passwords only — fingerprint output is not supported on this model. If you require a fingerprint-output reader, please contact customer service before ordering.
Ideal Applications
- Office buildings and corporate lobbies
- Residential complexes and gated communities
- Server rooms and restricted-access areas
- Retail back offices and warehouses
- Schools, gyms, and other public facilities
Learn More About Access Control Standards
For guidance on physical security systems and best practices, visit the NIST Cybersecurity Resources — a trusted authority on security standards and practices.
Frequently Asked Questions
Q: Is this RFID access control keypad suitable for outdoor use?
A: Yes. The keypad carries an IP67 waterproof rating, meaning it is fully protected against dust ingress and can withstand temporary water immersion. Its operating temperature range of -40°C to 60°C also makes it suitable for harsh outdoor environments year-round.
Q: What is the difference between the TF886, T886, and TC886 models?
A: All three models share the same zinc alloy touchpad design and support password and RFID card access. The key distinction is that the TF886 variant's Wiegand output supports cards and passwords only — fingerprint Wiegand output is not available on TF886. The T886 and TC886 models support full fingerprint functionality. Contact customer service if you need fingerprint-output Wiegand support.
Q: How many users can this access control system store?
A: This standalone keypad supports up to 1,000 RFID cards and up to 100 fingerprint profiles, making it well-suited for small to medium-sized facilities or departments.
Q: What Wiegand formats does this keypad support?
A: The keypad supports Wiegand output formats from 26-bit up to 34-bit, allowing seamless integration with a wide variety of existing access control panels and systems.
Q: What unlock methods are supported?
A: This all-in-one keypad supports three unlock methods: PIN password, 125kHz EM RFID card, and fingerprint recognition — offering flexible, multi-layered entry control for your premises.
