IP67 Fingerprint NFC RFID Access Controller – TTLock App Ready

IP67 Waterproof Fingerprint & RFID Access Control Panel with TTLock App

Take full control of who enters your property with this rugged, outdoor-grade access controller from Asia-Teco. Featuring a sleek zinc alloy body with a touch glass panel, IP67 waterproof protection, and multiple unlocking methods — fingerprint, NFC/RFID card, passcode, and smartphone app — this system delivers professional-level security for homes, offices, warehouses, and more. Seamlessly integrated with the TTLock App, you can manage access remotely from anywhere via Bluetooth 5.0 BLE and a compatible gateway.

Made in Mainland China.

Key Features

• IP67 Waterproof & Weatherproof — built for outdoor installation; operates reliably from -20°C to 70°C
• 4-in-1 Unlocking Methods — fingerprint, MIFARE M1 NFC/RFID card, PIN password, or TTLock smartphone app
• High-Accuracy Semiconductor Fingerprint Sensor — False Recognition Rate <0.001%; stores up to 500 fingerprints
• Large Card Capacity — supports up to 20,000 MIFARE M1 cards for enterprise-scale deployments
• 500 Individual Passwords — assign unique PIN codes for different users
• Bluetooth 5.0 BLE — fast, low-energy connectivity; compatible with Android 4.3+ and iOS 7.0+
• Remote Attendance & Monitoring — pair with an optional TTLock gateway for real-time access logs and remote management
• Durable Zinc Alloy Construction — embedded touch glass panel resists wear, impact, and harsh weather
• Wide Voltage Range — DC 12V–24V input; standby current just 7.4mA for energy efficiency

Technical Specifications

Who Is This For?

This access controller is ideal for residential gates, apartment complexes, office buildings, server rooms, warehouses, gyms, and any facility that requires reliable, multi-credential entry management. Its outdoor-rated IP67 enclosure means rain, dust, and extreme temperatures won't compromise performance.

Safety & Standards Reference

For general guidance on building access control and electronic security systems, the U.S. Consumer Product Safety Commission (CPSC) provides helpful resources on consumer electronics safety standards.

Frequently Asked Questions

Q: Does this fingerprint RFID access controller work outdoors in rain and extreme temperatures?

A: Yes. The controller carries an IP67 waterproof rating, meaning it is fully protected against dust ingress and can withstand immersion in water up to 1 meter for 30 minutes. It also operates across a wide temperature range of -20°C to 70°C, making it suitable for harsh outdoor environments year-round.

Q: How many users can be enrolled on this access control system?

A: The system supports up to 500 unique fingerprints, up to 500 individual PIN passwords, and up to 20,000 MIFARE M1 NFC/RFID cards — making it highly scalable for both small residential setups and large commercial facilities.

Q: Do I need a gateway to use the TTLock App remote access features?

A: The TTLock App communicates with the controller locally via Bluetooth 5.0 BLE when your phone is within range. To enable remote access, real-time attendance logs, and management from anywhere via the internet, an optional TTLock-compatible Wi-Fi or Ethernet gateway is required (sold separately).

Q: What type of power supply does this access controller need?

A: The controller accepts a DC 12V to 24V input, making it compatible with standard access control power supplies commonly used for electric locks and gate controllers. The low standby current of 7.4mA ensures energy-efficient continuous operation.

Q: Is the TTLock App available for both Android and iPhone?

A: Yes. The TTLock App is compatible with Android 4.3 and above, as well as iOS 7.0 and above, covering the vast majority of modern smartphones.
