IP67 Waterproof Dual-Frequency RFID Access Controller – 1000 Users

Asia-Teco IP67 Waterproof Dual-Frequency RFID Standalone Access Controller

Take control of who enters your space with the Asia-Teco Dual-Frequency RFID Standalone Access Controller. Supporting both 125KHz (EM) and 13.56MHz (Mifare) card formats, this all-in-one keypad unit offers flexible entry options — card swipe, PIN code, or card + PIN — making it one of the most versatile single-door controllers available. Ideal for office buildings, residential complexes, gyms, warehouses, and any high-traffic area requiring reliable, secure entry management.

Key Features

• Dual Frequency Support: Works with both 125KHz EM and 13.56MHz Mifare proximity cards, wristbands, and compatible bank cards.
• IP67 Waterproof Rating: Encapsulated in epoxy resin for full outdoor durability, operating in temperatures from -40°C to 70°C.
• Backlit Touch Keypad: Illuminated keys for easy night-time operation.
• Three Entry Modes: Card only, PIN code only, or Card + PIN combined for added security.
• 1,000 User Capacity: Store up to 1,000 cards, PINs, or card+PIN combinations.
• Wiegand Output: Compatible with a wide range of access control systems and panels via Wiegand interface.
• Ultra-Fast Response: Door unlocks in under 0.1 seconds after credential presentation.
• Doorbell Interface: Connect an external wired doorbell directly to the unit.
• User-Manageable PINs: Individual users can modify their own access PIN independently.
• Unattended Card Registration: Add cards conveniently without requiring administrative attendance.
• Data Sharing Across Devices: Register once, share data across multiple units to reduce setup workload.
• Fail-Secure Mode: Locks remain secure in the event of a power failure.
• Low Power Consumption: Quiescent current ≤100mA on a standard DC 12V supply.
• Fire-Retardant Housing: High-quality, durable casing built for long-term use.

Technical Specifications

Ideal Applications

This access controller is perfectly suited for:

• Office buildings and co-working spaces
• Residential communities and apartment complexes
• Gyms, clubs, and recreational facilities
• Warehouses and storage facilities
• Schools and educational campuses
• Any outdoor or exposed entry point requiring weatherproof security hardware

Made in Mainland China.

For guidance on access control standards and physical security best practices, visit the U.S. Consumer Product Safety Commission (CPSC).

Frequently Asked Questions

Q: What card types does this RFID access controller support?

A: The controller supports both 125KHz EM proximity cards and 13.56MHz Mifare cards simultaneously. It also works with compatible NFC-enabled wristbands and bank cards, giving you maximum flexibility in credential choice.

Q: Is this access controller suitable for outdoor installation?

A: Yes. The unit carries an IP67 waterproof rating thanks to its epoxy resin encapsulation, making it fully suitable for outdoor use. It operates reliably in temperatures ranging from -40°C to 70°C, making it ideal for harsh climates and exposed entry points.

Q: How many users can be stored on this standalone access controller?

A: The controller supports up to 1,000 users. This includes individual cards, individual PINs, or card + PIN combinations — giving you comprehensive management for small to medium-sized premises.

Q: Does the RFID access controller support integration with other access control systems?

A: Yes. The unit features a Wiegand output, making it compatible with a wide range of third-party access control panels and systems. This allows you to incorporate it into existing or larger security setups with ease.

Q: Can multiple units share the same user database?

A: Yes. The data mutual-copy function allows you to register users on one unit and share that data across multiple controllers, significantly reducing setup time and administrative workload when managing multi-door installations.
