Asia-Teco SF3-MF Waterproof Fingerprint & RFID Access Control System
Secure your property with confidence using the Asia-Teco SF3-MF IP66 Waterproof Access Control Reader. Designed for both indoor and outdoor installations, this rugged zinc-alloy fingerprint and RFID card reader supports up to 1,000 fingerprints and 2,000 card users (3,000 total user capacity), making it ideal for offices, apartment buildings, warehouses, gates, and more. Its anti-vandal metal housing and IP66 weather-resistance rating mean it performs reliably in rain, dust, and extreme temperatures.
Key Features
- IP66 Weatherproof: Fully protected against dust and powerful water jets — built for demanding outdoor environments.
- Dual Authentication: Supports fingerprint recognition AND 13.56MHz Mifare RFID card access for flexible, multi-layer security.
- Large User Capacity: Stores up to 1,000 fingerprints and 2,000 Mifare card credentials (3,000 total users).
- Anti-Vandal Metal Design: Zinc-alloy silver casing withstands physical tampering and harsh conditions.
- Wiegand 26–44 Bit Output: Integrates seamlessly with a wide range of existing access control panels and systems.
- Standalone Operation: Includes one onboard relay — no external controller required for basic use.
- Flexible Relay Output: NO/NC/Common relay with adjustable lock output time (0–99 seconds, 5-second default) and 2A maximum load.
- Pulse & Toggle Modes: Configure door unlock behavior to match your specific lock type and workflow.
- Multi-User Access & Interlock: Supports multi-fingerprint/card access combinations and a Principal User setting for administrator control.
- App-Based User Management: Upload and download user credentials conveniently via the companion app.
- Wide Operating Temperature: Standard range -30°C to 60°C; optional extended range -40°C to 60°C.
Technical Specifications
| Model | SF3-MF |
| User Capacity | 3,000 total (1,000 fingerprints + 2,000 cards) |
| Operating Voltage | 12V DC |
| Idle Current | <45mA |
| Card Technology | 13.56MHz Mifare |
| Read Range | 1–2 cm |
| Fingerprint Module | Optical, 500 DPI |
| Identification Time | <1 second |
| FAR / FRR | <0.001% / <0.01% |
| Wiegand Interface | 26–44 bit output |
| Relay Output | NO, NC, Common; 0–99 sec adjustable; 2A max |
| Wiring Connections | Relay output, exit button, alarm, door contact, Wiegand output |
| Operating Temperature | -30°C ~ 60°C (standard); -40°C ~ 60°C (optional) |
| Operating Humidity | 10%RH – 99%RH |
| Color | Silver |
| Dimensions | 135 × 55 × 26 mm |
| Unit Weight | 480g |
| Material | Zinc-Alloy |
| Country of Origin | Made in Mainland China |
Why Choose the SF3-MF?
Whether you're securing a commercial entry, a gated facility, or a multi-tenant building, the Asia-Teco SF3-MF delivers enterprise-grade access control in a compact, weather-resistant package. Its dual-authentication capability reduces unauthorized access, while app-based management makes adding or removing users fast and easy — no IT specialist required.
For guidance on physical security best practices for access control systems, visit the Cybersecurity & Infrastructure Security Agency (CISA) or review physical security standards at NIST Cybersecurity Resources.
Frequently Asked Questions
Q: Is the SF3-MF fingerprint access control reader truly waterproof for outdoor use?
A: Yes. The Asia-Teco SF3-MF carries an IP66 waterproof rating, meaning it is fully protected against dust ingress and powerful water jets from any direction. It is rated for operating temperatures from -30°C to 60°C (with an optional -40°C lower limit), making it suitable for a wide range of outdoor environments including gates, building entrances, and covered parking facilities.
Q: What types of credentials does this access control system support?
A: The SF3-MF supports two credential types: optical fingerprint recognition (up to 1,000 fingerprints stored) and 13.56MHz Mifare RFID cards or tags (up to 2,000 stored). Multi-credential combinations (e.g., card + fingerprint) can also be configured for enhanced security.
Q: Does this reader integrate with my existing access control panel via Wiegand?
A: Yes. The SF3-MF features a Wiegand 26–44 bit output interface, which is compatible with the vast majority of access control panels and door controllers on the market. It can also operate in standalone mode using its built-in relay, eliminating the need for a separate controller in smaller installations.
Q: How do I manage users on the SF3-MF access control system?
A: User credentials (fingerprints and card data) can be managed directly on the device or uploaded/downloaded wirelessly via the companion smartphone app. This makes it easy to add new users, remove former ones, or update access permissions without physically accessing the reader's wiring or internal memory.
Q: What lock types are compatible with this door access control system?
A: The SF3-MF is compatible with electric strikes, magnetic locks (maglocks), and other electric door locks that operate on a relay-controlled signal. The onboard relay supports both Fail-Safe (power-to-lock) and Fail-Secure configurations, with NO/NC/Common terminals and an adjustable output time from 0 to 99 seconds.
