IP55 Dual Swing Gate Opener 400kg DC24V Home Automation
IP55 Dual Swing Gate Opener 400kg DC24V Home Automation
Automate Your Driveway Entry with Heavy-Duty Dual Swing Gate Opener
Upgrade your home's entry with this professional-grade IP55-rated Dual Automatic Swing Gate Opener by KINGJOIN&GALO. Engineered for residential and light commercial use, this powerful system handles single-leaf gates up to 400 kg (per leaf) and up to 2.5 meters in length, delivering smooth, quiet, and reliable automated access every time. Made in Mainland China.
Key Features
- Heavy-Duty Capacity: Supports gate leaves weighing 300–400 kg each, ideal for heavy metal or timber gates.
- IP55 Weather Protection: Dust-resistant and jet-water-resistant housing ensures reliable all-weather performance — operating in temperatures from -40°C to +50°C.
- Flexible Voltage Input: Compatible with DC 24V, AC 110V, and AC 220V power supplies, making it suitable for both North American and international installations.
- Soft Start & Adjustable Speed: Gentle start function prevents gate jerk or mechanical stress; opening and closing speed can be fine-tuned for your specific gate weight and style.
- Auto-Close Function: Programmable auto-close with adjustable time delay keeps your property secure without manual intervention.
- Obstruction Detection: Gate automatically stops if it detects an obstruction, enhancing safety for people, pets, and vehicles.
- Manual Override: In the event of a power failure, a manual override key releases the clutch so you can open or close the gate by hand.
- Multiple Remote Transmitters: Accommodate several unique remote controls for household members or staff.
- Solar & Battery Backup Ready: Controller can be connected to a solar system or a DC 24V backup battery for uninterrupted operation.
- Expandable Accessories: Compatible with photocell sensors, keypads, gate locks (DC 24V), push buttons, flash light warnings, and other access control devices.
- Single or Dual Gate Mode: Configurable for either a single swing gate or dual swing gate setup.
- Fail Secure Mode: Security mode defaults to fail-secure with signal, maintaining gate position during power interruptions.
- Quiet Operation: Designed for smooth, near-noiseless performance — ideal for residential neighbourhoods.
- CE Certified: Meets CE safety and performance standards.
Technical Specifications
| Motor Voltage | 24V DC, 60W |
| Input Power | AC/DC 24V ±10% / 220V AC ±10% / 120V AC ±10% |
| Rotational Speed | 300 RPM |
| Arm Extension Speed | 2.4 cm/s |
| Arm Max Travel | 300 mm |
| Continuous Run Time | 5 minutes |
| Max Single-Leaf Length | 2.5 meters |
| Max Single-Leaf Weight | 300–400 kg |
| Max Gate Open Angle | 110° |
| Operating Temperature | -40°C to +50°C |
| Protection Class | IP55 |
| Security Mode | Fail Secure with Signal |
| Gross Weight (Dual Kit) | 18 kg |
| Certification | CE |
What's in the Box
- 2 × DC gate motors (pre-wired with motor cables)
- 2 × Override spanners
- 2+ × Remote controls
- 1 × Control panel
- 2 × Post mounting brackets
- 2 × Gate mounting brackets
- 1 × Rubber gate stop
- 1 × Instruction manual
Safety & Standards Reference
For guidance on electrical installation safety practices and product certification requirements relevant to automated gate systems, refer to the U.S. Consumer Product Safety Commission (CPSC) for general product safety standards, and OSHA's Electrical Safety resources for safe electrical installation practices.
Frequently Asked Questions
Q: Is this swing gate opener compatible with both AC 110V and AC 220V power supplies?
A: Yes. This gate opener system is designed to be flexible and supports DC 24V, AC 110V (±10%), and AC 220V (±10%) input power, making it suitable for residential installations in North America and internationally.
Q: Can I connect this dual swing gate opener to a solar panel system?
A: Absolutely. The controller is compatible with a solar power system as well as a DC 24V backup battery, allowing the gate to continue operating even during grid power outages or in off-grid locations.
Q: What happens if the gate encounters an obstacle while opening or closing?
A: The gate opener is equipped with built-in obstruction detection. If the gate arm encounters resistance, the motor stops automatically to prevent damage to the gate and ensure the safety of people or vehicles in the gate's path.
Q: Can additional access control accessories be added to this system?
A: Yes. The control panel supports a wide range of optional accessories including photocell sensors, keypads, DC 24V gate locks, push buttons, flash warning lights, and additional remote transmitters, giving you full flexibility to build out your access control setup.
Q: What is the IP55 protection rating on this gate opener?
A: IP55 means the unit is protected against dust ingress (sufficient to prevent harmful deposits) and against low-pressure water jets from any direction. This makes it suitable for outdoor installation in most weather conditions, from rain and dust to extreme temperatures between -40°C and +50°C.
