Get reliable, low-profile switching performance with the G5V-2 series miniature signal relay. Available in bulk packs of 5 to 50 units, this relay is engineered for precision signal circuit control in automation, consumer electronics, PCB designs, and communication equipment. Choose from multiple coil voltages and current ratings to match your exact circuit requirements.
Model Variants & Configurations
- G5V-2-5VDC / G5V-2-12VDC / G5V-2-24VDC — DPDT (2 Form C: 2NO + 2NC), 2A contact rating, 8-pin, coil voltages: 5VDC, 12VDC, 24VDC
- G5V-2-H1-5VDC / G5V-2-H1-12VDC / G5V-2-H1-24VDC / G5V-2-H1-48VDC — DPDT (2 Form C: 2NO + 2NC), 1A contact rating, 8-pin, coil voltages: 5VDC, 12VDC, 24VDC, 48VDC
Key Specifications
- Contact Configuration: DPDT — 2 Normally Open (NO) + 2 Normally Closed (NC)
- Pin Count: 8-pin DIP (through-hole, PCB mount)
- Contact Load: 1A (H1 series) / 2A (standard series)
- Coil Voltages Available: 5VDC, 12VDC, 24VDC, 48VDC (model dependent)
- Compact Dimensions: 20.5mm (L) × 10.1mm (W) × 11.5mm (H)
- Pack Size Options: 5, 10, 20, 30, 50 pieces — great for prototyping and production runs
- Application: Signal circuits, PCB boards, automation systems, telecom equipment
Why Choose the G5V-2 Series?
- ✅ Miniature footprint — fits easily on compact PCBs without sacrificing switching capability
- ✅ Versatile voltage options — compatible with 5V microcontrollers, 12V automotive systems, and 24V/48V industrial circuits
- ✅ DPDT switching — dual pole design for greater circuit flexibility
- ✅ Bulk value packs — cost-effective for engineers, hobbyists, and production teams alike
- ✅ Standard 8-pin DIP footprint — easy PCB integration with standard relay sockets
Common Applications
- PCB signal switching and routing
- Arduino / Raspberry Pi relay control modules
- Industrial automation and PLC interfaces
- Telecommunications and data switching equipment
- Consumer electronics prototyping
Made in Mainland China.
For electrical safety standards and best practices when working with relay circuits, refer to resources from the U.S. Occupational Safety and Health Administration (OSHA) — Electrical Safety.
Frequently Asked Questions
Q: What is the difference between the G5V-2 and G5V-2-H1 relay models?
A: The standard G5V-2 series supports a 2A contact current rating and is available in 5V, 12V, and 24V coil voltages. The G5V-2-H1 series has a 1A contact current rating and extends to a 48VDC coil voltage option, making it suitable for higher-voltage coil drive applications where lower contact loads are acceptable.
Q: Are these relays compatible with standard PCB relay sockets?
A: Yes. The G5V-2 series uses a standard 8-pin DIP through-hole footprint (20.5mm × 10.1mm × 11.5mm), making it compatible with widely available PCB relay sockets and direct PCB soldering setups.
Q: Can I use these miniature signal relays with a microcontroller like an Arduino?
A: The 5VDC coil variants are well-suited for use with Arduino and similar 5V microcontrollers, typically via a transistor driver circuit or a dedicated relay module board, since the relay coil may draw more current than a GPIO pin can supply directly.
Q: What does DPDT (2NO + 2NC) mean on this relay?
A: DPDT stands for Double Pole Double Throw. This relay has two independent switching poles, each with a Normally Open (NO) and a Normally Closed (NC) contact. This allows you to simultaneously switch two separate circuits when the relay coil is energized.
