Face Recognition Access Control & Time Attendance Terminal
Face Recognition Access Control & Time Attendance Terminal
Face Recognition Access Control & Time Attendance Terminal | 5" Touch Screen, RFID, Fingerprint
Upgrade your facility's entry management with this advanced AI-powered face recognition access control and time attendance terminal. Featuring a dual-camera WDR system, a 5-inch IPS touch screen, fingerprint scanning, 125KHz RFID card reading, and multi-user recognition in under 0.2 seconds — this all-in-one terminal keeps your premises secure and your workforce records accurate.
Made in Mainland China.
Why Choose This Terminal?
- Lightning-Fast Recognition: Identifies up to 5 users simultaneously in ≤0.2 seconds with 99.70% accuracy.
- Anti-Spoofing Dual Camera: WDR wide dynamic range binocular camera system detects live faces and rejects photos, videos, and printed images.
- Multiple Verification Modes: Dynamic face recognition, capacitive fingerprint, 125KHz RFID card, password, or QR code — choose what suits your workflow.
- Large Capacity: Stores up to 5,000 face profiles (upgradable to 20,000), 15,000 fingerprints, 15,000 card users, and 500,000 log records.
- Versatile Connectivity: Standard TCP/IP LAN, USB 2.0; optional Wi-Fi (+$20) and 13.56MHz RFID (+$8) upgrades available.
- 20-Language Support: Supports English, Spanish, Arabic, French, Portuguese, Italian, Japanese, Korean, Thai, Farsi, and more.
- Comprehensive Access Control I/O: Door sensor, relay output, alarm output, exit button, fire input, Wiegand 26/34 in/out, tamper detection, anti-passback, and interlock.
- Flexible Management Software: Compatible with Desktop, Cloud, SDK, and Mobile APP platforms. Export Excel attendance reports via USB flash drive.
Key Specifications
| Model | A103F (Asia-Teco) |
| Screen | 5-inch IPS Touch Screen, HD 720×1280 |
| Operating System | Linux 3.10 |
| CPU | 1.2GHz Quad-Core ARM |
| RAM / ROM | 256MB DDR3 / 4GB Flash |
| Cameras | Dual: 1/2.9" WDR 2MP color + 1/5" infrared live detection, FOV 75° each |
| Face Recognition Accuracy | 99.70% |
| Recognition Speed | ≤0.2s (up to 5 users simultaneously) |
| Recognition Distance | 0.5–2.5m (0.5–1.5m with live detection enabled) |
| Face Capacity | 5,000 (20,000 optional) |
| Fingerprint Capacity | 15,000 |
| Card Capacity | 15,000 (125KHz ID standard; 13.56MHz IC optional) |
| Log Records | 500,000 |
| Wiegand | Wiegand 26/34 input & output |
| Network | TCP/IP LAN; Wi-Fi optional (+$20) |
| Power Supply | DC 12V |
| Working Temperature | -15°C to +45°C |
| Languages | 20 languages including English, Spanish, Arabic, French, Japanese, Korean |
| Installation | Wall mount or desktop stand (bracket/floor stand optional) |
| Country of Origin | Made in Mainland China |
Optional Upgrades
- Wi-Fi Module: Add wireless LAN connectivity (+$20)
- 13.56MHz IC Card (MIFARE): Upgrade RFID for contactless smart cards (+$8)
- Extended Face Capacity: Upgrade from 5,000 to 20,000 face profiles
Ideal Applications
- Corporate offices, factories, and warehouses
- Schools, hospitals, and government buildings
- Hotels, gyms, and residential complexes
- Any facility requiring contactless, touchless entry management and automated attendance tracking
For more information on physical security and access control best practices, visit the NIST Identity & Access Management resource page.
Frequently Asked Questions
Q: How accurate is the face recognition on this access control terminal?
A: The terminal achieves a 99.70% face recognition accuracy rate, powered by a multi-task cascaded convolutional neural network (MTCNN) that performs dynamic face detection and tracking via live video stream. The dual-camera anti-spoofing system also prevents unauthorized entry using photos or videos.
Q: Can this terminal recognize multiple people at once during busy entry periods?
A: Yes. The system supports simultaneous recognition of up to 5 users at the same time in under 0.2 seconds, making it ideal for high-traffic environments such as factory entrances, office lobbies, and school gates.
Q: What connectivity options are available for managing attendance data?
A: The terminal supports standard TCP/IP wired LAN networking and USB 2.0 for data import/export. Optional Wi-Fi connectivity is available for an additional $20. Management is handled via Desktop software, Cloud platform, SDK integration, or Mobile APP. Attendance reports can be exported directly to Excel via USB flash drive.
Q: Does this terminal work in low-light or bright backlit environments?
A: Yes. The WDR (Wide Dynamic Range) dual-camera system supports accurate face recognition under strong light, low light, and backlit conditions. An automatic LED fill light activates based on ambient lighting (0–50,000 Lux range), ensuring reliable performance around the clock.
Q: What RFID card frequencies are supported?
A: The terminal comes standard with 125KHz RFID (ID card) support with a capacity of 15,000 users. An optional 13.56MHz IC card (MIFARE/smart card) upgrade is available for an additional $8 per unit.
