Dual Frequency RFID Reader Writer 125KHz 13.56MHz USB Desktop

Asia-Teco R10DC Dual Frequency RFID Card Reader & Writer

Meet the Asia-Teco R10DC — a compact, desktop USB reader/writer that handles both 125KHz and 13.56MHz contactless cards in a single device. Whether you're managing access control systems, hotel door locks, utility meters, or ID card management platforms, this 2-in-1 unit delivers fast, reliable performance with zero-driver installation required.

Why Choose the R10DC?

• Dual Frequency Support: Read and write both 125KHz ID cards and 13.56MHz ISO15693 IC cards with one device — no switching hardware needed.
• Driver-Free USB Connectivity: Uses HID protocol over USB 1.1 — just plug it in and go. Compatible with Windows 2000, XP, Vista, 7, CE, Linux, and Android.
• Fast Read Speed: Card detection in under 100ms, with a read distance of up to 80mm depending on card type.
• Developer-Ready SDK: Comes with a dynamic link library (DLL) driver development kit, demo programs, and multi-platform support — ideal for system integrators and developers.
• Built-In Watchdog Circuit: Ensures stable, reliable operation even in demanding environments.
• Ultra-Slim Desktop Form Factor: At just 104 × 68 × 10mm, it sits neatly on any desk or countertop without cluttering your workspace.

Technical Specifications

• Model: R10DC
• Brand: Asia-Teco
• Card Types Supported: 125KHz ID cards & 13.56MHz ISO15693 IC cards
• Working Frequencies: 125KHz / 13.56MHz
• Communication Interface: USB (HID protocol, driver-free)
• USB Standard: USB 1.1
• Read Distance: 0–80mm (varies by card type)
• Read Time: <100ms
• Power Supply: USB bus power, 5V
• Dimensions: 104 × 68 × 10mm
• Compatible OS: Windows 2000/XP/Vista/7/CE, Linux, Android
• Country of Origin: Made in Mainland China

Common Applications

• Access control & entrance guard systems
• Hotel door lock management
• Water, electricity, and gas meter card management
• Employee & visitor ID card systems
• Loyalty and membership card programming

For guidance on RFID security standards and best practices in access control, refer to the NIST Guidelines for Securing RFID Systems.

Frequently Asked Questions

Q: Does the dual frequency RFID reader require driver installation?

A: No. The Asia-Teco R10DC uses a standard USB HID protocol, making it completely driver-free. Simply plug it into any USB port on a Windows, Linux, or Android device and it is recognized automatically — no software installation needed before first use.

Q: What types of cards are compatible with this 125KHz and 13.56MHz reader writer?

A: The R10DC supports both 125KHz proximity ID cards and 13.56MHz ISO15693 contactless IC cards. This covers a wide range of common access control cards, hotel key cards, and utility meter cards used in commercial and residential systems.

Q: Can developers integrate this USB RFID reader into custom software applications?

A: Yes. The R10DC includes a comprehensive SDK featuring a dynamic link library (DLL), demo programs, and multi-platform development support, making it straightforward for developers to integrate RFID read/write functionality into custom access control, time-attendance, or card management applications.

Q: What is the maximum read distance of this desktop RFID reader?

A: The read distance is up to 80mm (approximately 3.1 inches), though the actual range depends on the specific card type and environmental conditions. For most standard access control cards, reliable detection occurs within 20–60mm of the reader surface.
