Detachable Drill Guide Set – Cabinet Hardware Punch Locator
Detachable Drill Guide Set – Cabinet Hardware Punch Locator
Detachable Drill Guide Set – Precision Punch Locator for Cabinet Hardware
Get perfectly aligned holes every single time with this Detachable Drill Guide Set. Whether you're installing cabinet pulls, drawer knobs, or door handles, this woodworking jig takes the guesswork out of hardware placement — delivering 1mm precision with fast, tool-free adjustments.
Key Features
- Quick-Release Drill Guide Block: Snaps in and out for fast, hassle-free setup so you can work efficiently on any project.
- Front-Mounted Clamp Handle: Keeps the jig firmly secured to your drawer or cabinet face while you drill — no slipping, no misalignment.
- Dual-Axis Adjustability: The L-bracket and top screws lock in the horizontal position; two large front thumbscrews dial in the vertical placement. One tool, endless configurations.
- Stainless Steel Ruler: Corrosion-resistant and built to last — the ruler won't wear down with heavy use, maintaining accuracy job after job.
- Fully Detachable Design: Separates into multiple components for compact storage and easy transport to job sites.
- 1mm Precision Scale: Measure and mark exact hole positions for pulls, knobs, and handles on drawers and doors.
Specifications
| Ruler Material | Stainless Steel |
| Slider Material | ABS Plastic |
| Vertical Scale | 25 cm |
| Horizontal Scale | 40 cm |
| Edge to Hole Center | 20 cm |
| Precision | 1 mm |
| Country of Origin | Made in China |
What's in the Box
- 1 × Detachable Drill Guide Set (complete)
Important Notes
- Minor dimensional variations may occur due to manual measurement methods.
- Product color may vary slightly from images due to photography lighting and monitor settings.
Learn More About Safe Tool Use
For best practices when using hand tools and drilling equipment in a workshop setting, visit the OSHA Hand and Power Tools Safety Guide.
Frequently Asked Questions
Q: What types of cabinet hardware can I install with this drill guide set?
A: This drill guide jig is designed for precise installation of cabinet pulls, drawer knobs, handles, and similar hardware. Its dual-axis adjustment system accommodates a wide range of hardware hole spacings on both drawers and doors.
Q: Is the drill bit included with the cabinet hardware drill guide?
A: No, drill bits are not included. The set includes the complete detachable drill guide jig with the stainless steel ruler, ABS plastic slider, clamp handle, and all adjustment hardware. Standard drill bits are used separately with the guide sleeve.
Q: How accurate is this woodworking punch locator?
A: The drill guide set offers 1mm precision with a 25 cm vertical scale and 40 cm horizontal scale, and an edge-to-hole-center measurement of 20 cm — making it one of the most accurate template jigs available for cabinet hardware installation.
Q: Is this drill guide jig suitable for beginners?
A: Absolutely. The quick-release drill guide block, front-mounted clamp handle, and large thumbscrews make setup straightforward even for DIY beginners. No complex calibration is needed — just clamp, adjust, and drill.
