Asia-Teco DC 12V Stainless Steel Electric Rim Lock for Access Control Systems
Upgrade your home, office, or commercial space with the Asia-Teco DC 12V Electric Door Rim Lock — a heavy-duty stainless steel electronic gate lock built for reliable, low-noise automated access control. Whether you're securing a residential building, school, hotel, or factory warehouse, this integrated rim lock delivers fast, quiet, and dependable performance with every use.
Key Features
- Auto-Locking: Door locks automatically upon closing — no manual intervention needed.
- Universal Fit: Compatible with left-hand, right-hand, in-swing, and out-swing doors.
- Versatile Door Compatibility: Works with wooden, steel, and stainless steel doors (thickness 4–11 cm).
- Multiple Unlock Methods: Supports electrical control, key operation, or manual hand operation. Includes 3 keys.
- Power-Fail Safe: Can be opened from inside and outside with keys even without power supply.
- Low Static Power Consumption: Only 25 mA static current — energy-efficient and long-lasting.
- Corrosion-Resistant Finish: Steel wire-drawing processed surface ensures durability and a clean aesthetic.
- High Sensitivity: Unlocks in ≤1 second with virtually silent operation.
- Rated Lifespan: Up to 500,000 lock/unlock cycles for long-term reliability.
- Wide Temperature Range: Operates reliably from -40°C to 50°C (-40°F to 122°F).
Technical Specifications
| Working Voltage | DC 12V – 18V |
| Unlock Current | <350 mA |
| Static Current | 25 mA |
| Unlock Time | ≤1 second |
| Lock Bolt Length | >20 mm |
| Door Thickness | 4–11 cm |
| Material | Stainless Steel |
| Rated Lifespan | 500,000 cycles |
| Operating Temperature | -40°C to 50°C |
| Operating Humidity | 10%–90% RH |
Ideal Applications
This electric rim lock is well-suited for a wide range of environments, including:
- Residential apartment buildings and homes
- Schools and educational institutions
- Hotels and hospitality facilities
- Office buildings and government facilities
- Factory warehouses and commercial storage areas
- Public entry and exit gates
Made in Mainland China.
For guidance on electronic security standards and best practices for access control installations, refer to the U.S. Consumer Product Safety Commission (CPSC).
Frequently Asked Questions
Q: Does this electric rim lock work if the power goes out?
A: Yes. The Asia-Teco electric door rim lock includes a manual key override feature. Even without power, you can unlock the door from both inside and outside using one of the 3 included keys, ensuring you're never locked out during a power outage.
Q: What types of doors is this electric gate lock compatible with?
A: This electronic rim lock is compatible with wooden doors, steel doors, and stainless steel doors with a thickness between 4 and 11 cm. It also supports left-hand, right-hand, in-swing, and out-swing configurations, making it highly versatile for residential and commercial installations.
Q: What access control methods does this lock support?
A: The lock supports three access methods: electrical control (compatible with most standard access control systems), physical key operation (3 keys included), and manual hand operation. This flexibility makes it easy to integrate into existing security setups.
Q: What is the working voltage for this electric rim lock?
A: The lock operates on DC 12V to 18V, making it compatible with standard access control power supplies. The static current draw is only 25 mA, keeping energy consumption low during standby.
