DC12V 5A 50W Door Access Control Switch Power Supply
DC12V 5A 50W Door Access Control Switch Power Supply
DC12V 5A 50W Door Access Control Switch Power Supply | AC 110–240V
Keep your building's entry points secure and reliably powered with this heavy-duty DC12V 5A 50W Door Access Control Switch Power Supply. Designed for a wide range of access control systems, electric locks, and building intercoms, this unit delivers stable, consistent output with built-in multi-layer protection for long-lasting performance. Made in Mainland China.
Why Choose This Access Control Power Supply?
- Universal AC Input: Accepts AC 110V–240V for worldwide compatibility — ideal for commercial and residential installations alike.
- Stable DC 12V / 5A Output: Provides a clean, reliable 5A current to power electric locks, intercoms, and access controllers without overloading the system.
- Triple Control Methods: Supports high, low, and switch control modes to suit a variety of access control configurations.
- Comprehensive Protection: Built-in overcurrent, overvoltage, and short circuit protection safeguard your equipment and wiring.
- Battery Anti-Polarity Protection: If the backup battery is connected in reverse, only the fuse is affected — the power supply unit itself remains undamaged.
- Overdischarge Battery Protection: Automatically disconnects the battery when voltage drops below 9.5V during battery-powered operation, extending battery life.
- Adjustable Delay Timer: New upgraded design allows time delay adjustment from 0 to 15 seconds for flexible door-unlock timing.
- 50W High-Power Transformer: Delivers robust, interference-resistant performance even in demanding, multi-device installations.
- Remote Control Module Lock Slot: Integrated slot in the access control system for easy remote control module integration.
- Reduces Controller Load: Offloads power demands from the access controller, simplifying wiring and reducing potential points of failure.
- External Connection Interface: Convenient external terminals make wiring and installation straightforward.
- Durable Metal Construction: Robust metal enclosure for long-term durability in professional installations.
Specifications
| Model | A208K |
| Condition | 100% Brand New |
| Material | Metal |
| Dimensions | Approx. 212 × 168 × 70 mm (8.3 × 6.6 × 2.7 in) |
| Weight | Approx. 1041 g |
| Input Voltage | AC 110V–240V |
| Output Voltage | DC 12V |
| Output Current | 5A |
| Power | 50W |
| Lock Output Voltage | DC 12V, NO / NC Selectable |
| Delay Range | 0–15 seconds (adjustable) |
| Origin | Made in Mainland China |
Applications
This power supply is purpose-built for:
- Building intercom systems
- Electric door lock drivers (magnetic locks, electric strikes)
- Access control panels and readers
- Entry/exit control for offices, apartment buildings, warehouses, and more
Notes
- Please allow 1–3 cm variance due to manual measurement.
- Monitor color calibration may cause slight color differences from the actual product. Please refer to the physical item as the standard.
For general guidance on electrical safety standards for power supply equipment, visit the U.S. Consumer Product Safety Commission (CPSC).
Frequently Asked Questions
Q: What types of electric locks is this door access control power supply compatible with?
A: This DC12V 5A power supply is compatible with a wide variety of electric locks, including magnetic locks, electric strikes, and electric bolts that operate at DC 12V. It supports both Normally Open (NO) and Normally Closed (NC) lock configurations, making it highly versatile for most access control installations.
Q: Does this power supply support a backup battery connection?
A: Yes. This access control power supply includes a backup battery connection interface with anti-polarity protection and overdischarge protection. If the battery voltage drops below 9.5V, the unit automatically disconnects it to prevent damage — and if the battery is connected in reverse, only the fuse is affected, keeping the main unit safe.
Q: What does the adjustable delay timer do?
A: The adjustable delay timer (0–15 seconds) controls how long the electric lock remains unlocked after an access event is triggered. This allows you to set the exact door-open duration that suits your security requirements — from a brief 1-second release to a full 15-second window.
Q: Is this power supply suitable for both residential and commercial access control systems?
A: Absolutely. With a universal AC 110V–240V input, 5A output current, and 50W high-power transformer, this unit is well-suited for both residential building intercom systems and larger commercial access control deployments with multiple electric locks or entry points.
