DC 12V Silent Intelligent Motor Electric Lock – Self-Closing Access Control Lock
Upgrade your access control setup with the XM-1200A DC 12V Silent Intelligent Motor Electric Lock. Engineered for quiet, reliable operation, this self-closing electronic lock is ideal for residential, commercial, and institutional applications. With a steel lock body and copper cylinder, it delivers lasting durability and smooth, virtually silent locking every time power is applied.
Key Features
- Silent Operation: Designed with a precision motor mechanism that locks and self-closes with minimal noise — perfect for offices, hotels, schools, and residences.
- Self-Closing Design: Automatically returns to the locked state upon power engagement, ensuring doors are never left unsecured.
- Locked When Powered On: Locks engage when power is applied (fail-secure design), providing reliable access control at all times.
- Durable Construction: Steel lock body with a copper lock cylinder for long-term performance in high-traffic environments.
- Certified & Safe: CE and FCC certified for safety and electromagnetic compliance.
- Wide Application: Suitable for residential buildings, public entrances, government offices, schools, hotels, factories, warehouses, and more.
Technical Specifications
| Model | XM-1200A |
| Voltage | DC 12V |
| Working Current | 2A |
| Locking Mode | Locked when power is on (Fail-Secure) |
| Lock Body Material | Steel |
| Lock Cylinder Material | Copper |
| Weight | 1.5 kg |
| Certification | CE, FCC |
| Country of Origin | Made in China |
Ideal Applications
This intelligent electric lock is a versatile solution for a wide range of entry points, including:
- Residential apartment and building doors
- Public facility and institutional entrances
- School and university access points
- Hotel room and corridor doors
- Factory floors and warehouse entrances
- Government and office building access
For general guidance on electronic access control security standards, visit the U.S. Consumer Product Safety Commission (CPSC) for consumer safety resources.
Frequently Asked Questions
Q: What does "locked when powered on" mean for the XM-1200A electric lock?
A: "Locked when powered on" means the lock engages and secures the door as soon as DC 12V power is applied. This is a fail-secure configuration — if power is lost, the lock releases, allowing free exit. This setup is common in access-controlled environments where controlled entry is the priority.
Q: What types of doors is this DC 12V motor electric lock compatible with?
A: The XM-1200A is designed for a broad range of door types including wood, metal, and composite doors found in residential buildings, hotels, schools, offices, factories, and warehouses. Always verify your door frame dimensions and power supply compatibility before installation.
Q: Is this electric lock easy to install and integrate with an existing access control system?
A: Yes. The lock operates on a standard DC 12V / 2A supply, making it straightforward to integrate with most standard access control systems, keypads, card readers, and intercoms. It is recommended to consult a licensed electrician or access control specialist for installation to ensure proper wiring and compliance with local building codes.
Q: What certifications does the XM-1200A electric lock hold?
A: The XM-1200A holds both CE (European Conformity) and FCC (Federal Communications Commission) certifications, confirming it meets established safety and electromagnetic compatibility standards for consumer and commercial use.
