BLE RFID Smart Hotel Door Lock | Web-Managed System – JCSMARTS

JCSMARTS BLE RFID Online Hotel Lock System for Wooden Doors

Upgrade your hotel or guesthouse security with the JCSMARTS JCHDSR918 Online BLE RFID Hotel Door Lock. Built from polished stainless steel and designed for wooden doors (38–65 mm thickness), this smart lock combines Bluetooth (BLE) connectivity with RFID card access and a powerful web-based management platform — all hosted securely on your own local LAN server. Made in Mainland China.

⚠️ Important Note: Ordering the lock alone does not include the card-issuing software or RFID cards. A complete system (encoder, server, gateway) is required to set up and operate the full hotel management suite. Please contact JCSMARTS for a full system quotation before ordering.

Key Features

• Multiple Unlock Methods: RFID card, remote control (via gateway), and mechanical key backup
• Bluetooth (BLE) + Optional 433MHz: Real-time communication with the central server via gateway
• RFID Card Support: 13.56 MHz MIFARE card compatible
• Reversible Direction: Flexible installation for left- or right-handed doors
• CE Certified | Polished Stainless Steel Body
• Battery Powered: 4× AA batteries | Battery life: 4–8 months with low-power alarm
• Fits Standard #3 ANSI Mortise (5050)

Advantages of the Online Hotel Lock Management System

1. Centralized Management

• Automatic upload of lock activity logs
• Automatic clock correction across all locks
• Online low-battery alerts per lock
• Real-time access authority management — revoke access remotely in seconds

2. LAN Server Architecture

• Runs entirely on your local network — no internet connection required
• No annual cloud fees; no risk of third-party data exposure
• Low system load, stable and fast to reboot
• Once deployed, operates independently of manufacturer software updates

3. Secure, Self-Hosted Data

• All data stored on your own server hardware — you choose Windows or Linux
• No data uploaded to external clouds; fully under your control

4. Cross-Platform Compatibility

• Browser-based (B/S architecture): access from Windows, macOS, Android, or Linux
• Open HTTP Web API for easy integration with PMS, kiosk, or third-party systems

5. Multi-Staff Operations

• Create multiple receptionist and staff accounts with flexible permission levels

6. Localization & Customization

• Customize the interface background and title
• Import translations into the system for local language support

System Components Required

1. LAN Server: Runs the core hotel lock software; all devices connect via LAN. Open HTTP API for PMS/kiosk integration.
2. Router: Standard LAN router (available locally).
3. Computer: Any device with a modern web browser — no client app installation needed.
4. Encoder: RJ45 LAN interface, supports static IP and DHCP; used to issue RFID cards via software.
5. Handset Programmer: For installing and configuring locks, correcting clock, emergency card issuing, log collection, and firmware updates.
6. Gateway (Optional): Enables remote unlock, remote checkout, lock log sync, lost card reporting, passage mode configuration, and energy monitoring.

Lock Hardware Specifications

Reception Dashboard Highlights

• Visual room map with real-time status — color-coded by occupancy and battery level
• Search rooms by building, floor, or type
• Pending operation alerts and quick authorization management
• Card quick menu: view card details, recycle/blank cards, extend stays, and check out guests instantly
• Master card, Building card, and Floor card support for tiered staff access
• Remote unlock from the front desk (requires gateway) — no need to send staff to the door

System Integration

Full HTTP API integration for third-party PMS and kiosk systems. Supports card issuing, stay extension, checkout, and data sync — compatible with any platform, no proprietary DLL or binary files required.

For more information on best practices in commercial access control systems, visit the U.S. Consumer Product Safety Commission (CPSC) for guidance on product safety standards.

Frequently Asked Questions

Q: Does ordering just the lock include the hotel management software and RFID cards?

A: No. The lock alone does not come with RFID cards or software setup capability. You need the full system — including an encoder, LAN server, and handset programmer — to configure locks and issue cards. Contact JCSMARTS at sales@jcsmarts.com for a complete system quotation.

Q: Does the BLE RFID hotel lock system require a constant internet connection?

A: No. The system operates entirely over your local LAN network. Internet access is not required for day-to-day operations such as card issuing or lock management. This also means your guest data stays on your own server with no third-party cloud exposure.

Q: What door thickness and mortise type does the JCHDSR918 lock fit?

A: The lock fits wooden doors with a thickness of 38–65 mm and requires a standard #3 ANSI mortise (5050). The open direction is reversible to accommodate both left- and right-handed door configurations.

Q: How long do the batteries last, and is there a low-battery warning?

A: The lock runs on 4× AA batteries with a typical lifespan of 4–8 months under normal use. The system includes a low-power alarm that notifies the central management dashboard when a lock's battery needs attention.

Q: Can the system integrate with our existing Property Management System (PMS)?

A: Yes. The JCSMARTS hotel lock system features an open HTTP Web API, allowing seamless integration with any PMS, kiosk, or third-party platform — regardless of operating system. It supports card issuing, stay extensions, checkouts, and full data synchronization with no platform restrictions.
