Bidirectional Thyristor Module — 5A to 100A, 1000V
Upgrade your power electronics projects with this high-performance bidirectional thyristor (TRIAC) module, available in multiple current ratings — 5A, 10A, 20A, 30A, 50A, and 100A — all rated at 1000V. Compatible with KP100.58 and M220.58 packaging formats, this module is ideal for AC power switching, motor speed control, lighting dimming, heating regulation, and other industrial or DIY power control applications.
Made in Mainland China.
Key Specifications
- Type: Bidirectional Thyristor (TRIAC) Module
- Current Ratings Available: 5A, 10A, 20A, 30A, 50A, 100A
- Max Forward & Reverse Voltage: 1000V
- Max Forward & Reverse Current: 150A (peak)
- Operating Voltage: 220V AC
- Packaging: KP100.58 / M220.58
- Condition: Brand New
- Customization: Available
⚠️ Important Selection Guidelines
1. Choosing the Right Current Rating
The current rating printed on the module represents the average on-state current — not the continuous RMS operating value. Always allow generous headroom based on your actual load conditions:
- Resistive loads: Multiply actual current (A) × 2 to 2.5 = required module nominal current
- Inductive loads: Multiply actual current (A) × 6 to 7 = required module nominal current
2. Heat Sink Requirement
When operating at currents above 5A, a suitable heat sink must be installed to ensure safe, stable performance. Do not operate at higher currents without proper thermal management.
Common Applications
- AC motor speed control
- Industrial heating element regulation
- Light dimming and switching circuits
- Power factor correction systems
- Soft-start circuits and AC switching relays
Why Choose This Thyristor Module?
- ✅ Wide current range — one listing covers multiple project needs
- ✅ High 1000V voltage rating for demanding applications
- ✅ Standard KP100.58 / M220.58 form factor — easy drop-in integration
- ✅ New condition with customization options available
- ✅ Suitable for both professional engineers and advanced hobbyists
For further technical guidance on power semiconductor safety and standards, refer to the U.S. Consumer Product Safety Commission (CPSC) and OSHA Electrical Safety Guidelines.
