520nm Green Laser PWM LED Module – 2.8W Adjustable Power, 12V AC
This high-performance 520nm green laser LED module delivers exceptional beam clarity and long-range visibility, making it ideal for ground marker applications, outdoor signaling, and bird deterrent systems. Synthesized from two precision 1.6W laser diodes, this module outputs approximately 2.8–2.9W of combined power with a wide 30mm (3cm) beam diameter at the exit aperture.
Key Features
- Wavelength: 520nm (green)
- Output Power: ~2.8–2.9W (dual 1.6W laser diodes)
- Beam Diameter: ~30mm (3cm) at exit, via integrated beam expander
- Visibility Range: ~100m in direct sunlight | ~500m in overcast/rainy conditions | 1,000–2,000m at night
- Power Source: AC, 12V / 5A required
- PWM / TTL Modulation: Supports 0–5V PWM signal input; frequency <18KHz
- Adjustable Power: Output intensity controlled via PWM signal for versatile applications
- Non-focusable beam – fixed expanded beam design
- Made in Mainland China
Ideal Applications
- Ground marker and position indicator lighting
- Bird deterrent and wildlife dispersal (effective up to ~100m in sunlight)
- Outdoor signaling and long-range beam visibility
- PWM-controlled laser systems and TTL-modulated setups
- Scientific, industrial, and hobbyist laser projects
Technical Specifications
| Wavelength | 520nm |
| Power Output | ~2.8–2.9W |
| Beam Diameter | ~30mm at exit |
| Operating Voltage | 12V DC (5A supply required) |
| PWM Signal | 0–5V, Frequency <18KHz |
| Modulation | TTL compatible |
| Batteries Included | No |
| Bulbs Included | No |
| Origin | Mainland China |
⚠️ Important Safety Warnings – Please Read Before Purchase
- Eye Hazard: This is a high-power laser module. Direct eye exposure is strictly prohibited and may cause permanent blindness. Always use appropriate laser safety eyewear. Use at your own risk.
- Fire Risk: Do not operate in flammable or gaseous environments. Risk of fire or explosion.
- Keep Away from Children: This product is not suitable for children. Keep out of reach at all times.
- Power Requirements: Must be driven by a stable 12V / 5A power supply. Insufficient power may damage the module.
- Do Not Disassemble: Opening the module may cause irreparable damage and voids any warranty.
- PWM/TTL Input: Signal range 0–5V, frequency must remain below 18KHz.
For general laser safety guidelines, refer to the U.S. Consumer Product Safety Commission (CPSC) Laser Safety Resources.
Frequently Asked Questions
Q: What power supply does the 520nm green laser PWM module require?
A: This laser module requires a stable 12V / 5A AC power supply to operate correctly. Using an undersized or unstable power supply may result in reduced performance or damage to the module.
Q: Can the 520nm laser module be focused to a tighter beam?
A: No — this module features a fixed, non-focusable beam. The beam is expanded to approximately 30mm (3cm) in diameter at the exit via an integrated beam expander. The design is optimized for wide-area visibility and ground marker use rather than pinpoint focusing.
Q: How does PWM/TTL modulation work with this laser module?
A: The module supports PWM (Pulse Width Modulation) and TTL modulation via a 0–5V signal input at frequencies below 18KHz. This allows you to adjust the laser's output power dynamically using a compatible controller, microcontroller, or signal generator.
Q: Is this laser module safe for outdoor bird deterrent use?
A: This module is suitable for outdoor bird deterrent applications and can effectively deter birds within approximately 100 meters under direct sunlight. Always follow local regulations regarding laser use outdoors and ensure the beam path is clear of people and animals at all times.
