2810 Brushless Motor – High Thrust RC Drone Motor for 7–8 Inch FPV Builds
Take your FPV freestyle or long-range drone build to the next level with the 2810 Brushless Motor. Available in four KV ratings — 900KV, 1100KV, 1300KV, and 1500KV — this motor delivers impressive thrust (up to 2.9 kg) in a compact 34.30 mm diameter frame. Built with a 12N14P (12 slot, 14 pole) stator configuration, it provides smooth, efficient power delivery ideal for 7 and 8-inch propellers on FPV racing, freestyle, and DIY drone platforms.
Made in Mainland China.
Why Choose the 2810 Brushless Motor?
- Multiple KV Options: Choose the exact KV rating to match your propeller size, battery voltage, and flying style.
- High Thrust Output: Generates 2.4–2.9 kg of thrust depending on KV variant — ideal for heavier payloads or aggressive flight profiles.
- 12N14P Configuration: 12 slots and 14 poles for smooth, low-cogging rotation and excellent efficiency at mid-to-high throttle.
- Compact Form Factor: 34.30 mm outer diameter fits standard 7–8 inch FPV drone frames without modification.
- Versatile DIY Application: Perfect for custom FPV builds, quad rebuilds, aerial photography platforms, and RC hobby projects.
Specifications by KV Variant
| KV Rating | Max Thrust | Outer Diameter | Configuration |
|---|---|---|---|
| 900KV | 2.7 kg | 34.30 mm | 12N14P |
| 1100KV | 2.4 kg | 34.30 mm | 12N14P |
| 1300KV | 2.9 kg | 34.30 mm | 12N14P |
| 1500KV | 2.5 kg | 34.30 mm | 12N14P |
Package Contents
- 1× 2810 Brushless Motor (KV variant of your choice)
Notes
- Battery not included.
- Colors may vary slightly due to screen and lighting differences.
- Please allow a tolerance of 1 mm–1 cm due to manual measurement.
For general guidelines on safe operation of RC drone components and consumer electronics, visit the U.S. Consumer Product Safety Commission (CPSC).
Frequently Asked Questions
Q: What propeller size is recommended for the 2810 brushless motor?
A: The 2810 brushless motor is designed for use with 7-inch and 8-inch propellers on FPV drone frames. Pairing with the appropriate prop size and battery voltage for your chosen KV rating will maximize thrust efficiency and flight performance.
Q: What is the difference between the 900KV, 1100KV, 1300KV, and 1500KV versions?
A: KV rating indicates how many RPM the motor spins per volt of input (with no load). Lower KV motors (900KV) typically pair with larger propellers and higher cell-count batteries for greater torque, while higher KV motors (1500KV) spin faster and suit smaller props and faster FPV flight styles. The 1300KV variant offers the highest maximum thrust at 2.9 kg among all available options.
Q: Is this 2810 brushless drone motor compatible with standard ESCs?
A: Yes, the 2810 12N14P brushless motor is compatible with standard 3-wire brushless ESCs (Electronic Speed Controllers) commonly used in FPV and DIY drone builds. Ensure your ESC is rated for the motor's current draw at your intended battery voltage.
Q: Does this motor come with mounting hardware?
A: The package includes one brushless motor. Mounting screws and hardware may vary; please verify compatibility with your specific drone frame's motor mount pattern before ordering.
