2-6S LiPo Power Module – Voltage & Current Meter for Multirotor Flight Controllers

Get precise, real-time power monitoring for your multirotor build with this compact 2-6S LiPo Power Module. Supporting input voltages up to 28V and delivering a stable 5.3V / 3A output, this power module is the ideal companion for flight controllers that require both regulated power and accurate telemetry data. Pre-soldered, pre-calibrated, and covered in transparent heat-shrink tubing — it's truly plug-and-play right out of the box.

Made in Mainland China.

Key Features

  • Wide Input Range: Compatible with 2S to 6S LiPo batteries (7.4V – 25.2V nominal, up to 28V maximum)
  • Regulated Output: Delivers a stable 5.3V at up to 3A for powering your flight controller and peripherals
  • High-Current Measurement: Measures up to 90A of current draw for comprehensive power monitoring
  • 5V ADC Compatible: Voltage and current outputs matched to 5V ADC for seamless integration with popular flight controllers
  • Pre-Assembled & Ready to Use: Connection lines and plugs are fully soldered, calibrated, and covered with transparent heat-shrink tubing to prevent short circuits
  • Compact Form Factor: Measures just 25mm × 21mm × 9mm — fits neatly into tight builds

Technical Specifications

Input Voltage 2~6S LiPo (max 28V)
Output Voltage 5.3V
Maximum Output Current 3A
Maximum Measurement Current 90A
ADC Compatibility 5V ADC
Board Dimensions 25mm × 21mm × 9mm
Heat Shrink Tubing Included (transparent)

What's in the Box?

  • 1× 2-6S LiPo Voltage & Current Power Module (pre-soldered and calibrated)

Notes

  • Due to lighting and display differences, actual product color may vary slightly from images.
  • Please allow 1mm–10mm variance due to manual measurement.

For guidance on safe handling of lithium batteries used with modules like this, refer to the U.S. Consumer Product Safety Commission – Battery Safety Resource.

Frequently Asked Questions

Q: Which flight controllers is this 2-6S LiPo power module compatible with?

A: This power module is compatible with most popular multirotor flight controllers that accept a 5V ADC input for voltage and current sensing, including APM, Pixhawk, and similar open-source platforms. Always verify your flight controller's power input requirements before connecting.

Q: Does this power module come pre-calibrated and ready to use?

A: Yes! The module arrives fully pre-soldered, pre-calibrated, and covered with transparent heat-shrink tubing. Simply plug it into your flight controller and LiPo battery — no additional setup or soldering is required.

Q: What is the maximum current this module can measure?

A: The power module supports a maximum measurement current of 90A, making it suitable for a wide range of multirotor configurations from smaller quads to high-power hexacopters and octocopters.

Q: Can this module be used with a 6S LiPo battery?

A: Yes. The module supports 2S through 6S LiPo batteries with a maximum input voltage of 28V, covering the full range of 6S battery voltages under load.
