Asia-Teco 12V Solenoid Electric Door Lock Catch – Model LKmini08
Take full control of your door or gate access with this compact, reliable 12V solenoid electric door lock catch from Asia-Teco. Designed for seamless integration into access control systems, this spring-loaded latch lock automatically secures the door when power is off and releases instantly when current is applied — making it ideal for keypad entry systems, intercoms, and automated gate setups.
Key Features
- Fail-Secure Design: Lock tongue extends (locks) when power is OFF via internal spring force; retracts (unlocks) when power is ON — keeping your space secure even during power interruptions.
- Fast Unlock Response: Unlocks in just 1 second after power is applied, for smooth, low-delay access.
- Compact Latch Stroke: 4.4mm tongue travel — precise and reliable for standard door and gate frames.
- Simple 2-Wire Connection: Red wire to positive (+), green wire to negative (−) — no complex wiring required.
- Broad Compatibility: Works with most access control panels, keypads, card readers, remote controllers, and intercom systems operating at DC 12V.
- Durable Build: Sturdy housing suitable for interior doors, cabinets, gates, and light-duty access points.
- Made in China by Asia-Teco (Model: LKmini08).
Technical Specifications
| Model | LKmini08 |
| Brand | Asia-Teco |
| Input Voltage | DC 12V |
| Input Current | 0.4A |
| Unlock Time | 1 second |
| Latch Stroke | 4.4mm |
| Power Mode | Interrupted (Fail-Secure) |
| Wiring | Red (+) / Green (−) |
| Origin | Made in China |
Installation Instructions
- Connect the red wire to the positive (+) terminal of your DC 12V power supply.
- Connect the green wire to the negative (−) terminal.
- When power is supplied, the lock tongue retracts 4.4mm — the door is unlocked.
- When power is cut, the internal spring forces the tongue to extend 4.4mm — the door is locked.
- Mount the unit to your door frame using the included assembly hardware and align with your door's strike plate.
Ideal Use Cases
- Residential and commercial door access control
- Gate and cabinet locking systems
- Keypad, card reader, and intercom-integrated entry systems
- Automated access control for offices, warehouses, and more
For general guidance on electrical safety when installing access control hardware, visit OSHA's Electrical Safety Resource.
Frequently Asked Questions
Q: Is this solenoid door lock fail-secure or fail-safe?
A: This electric door lock catch is fail-secure. When power is OFF, the internal spring keeps the latch tongue extended, keeping the door locked. Power must be applied to retract the tongue and unlock the door. This is ideal for security-sensitive applications where you want doors to remain locked during a power outage.
Q: What power supply does this solenoid lock require?
A: The lock requires a DC 12V power supply at 0.4A. It is compatible with standard 12V DC access control power supplies. Make sure your power source matches these specifications for reliable, safe operation.
Q: Can this electric door lock catch work with my existing access control system?
A: Yes — the Asia-Teco LKmini08 is designed to integrate with most standard access control panels, keypads, card readers, remote controllers, and intercom systems that output a DC 12V switched signal. Simply wire the red and green leads to your controller's lock output terminals.
Q: How difficult is the installation?
A: Installation is straightforward. The unit uses a simple 2-wire connection (red to positive, green to negative) and mounts to your door frame. Basic DIY skills and standard tools are sufficient. Always ensure power is off before making electrical connections and follow local electrical codes.
